LC320WUN-SCB1 51 Pins 1920*1080 60Hz LCD Screen for TV Sets
Product Details:
| Place of Origin: | China |
| Brand Name: | LG |
| Model Number: | LC320WUN-SCB1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LC320WUN-SCB1 | Diagonal Size: | 32.0" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 1920(RGB)×1080, FHD 69PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 698.4(W)×392.85(H) Mm |
| Support Color: | 16.7M/1.06B 100%sRGB | Backlight: | EEFL, 50K Hours, With Inverter |
| Used For: | TV Sets | Refresh Rate: | 60Hz |
Product Description
LC320WUN-SCB1 51 Pins 1920*1080 60Hz LCD Screen for TV Sets
LC320WUN-SCB1 LCD Panel Product details :
| Brand | LG Display |
| Model P/N | LC320WUN-SCB1 |
| Diagonal Size | 32.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD 69PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 698.4(W)×392.85(H) mm |
| Bezel Opening | 703.8(W)×398.4(H) mm |
| Outline Dim. | 760(H)×450(V)×49(D) mm |
| Treatment | Antiglare (Haze 10%), Hard coating (3H) |
| Luminance | 500 cd/m² (Typ.) |
| Contrast Ratio | 1450:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 5 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Min.)(CR>10) |
| Operating Mode | S-IPS, Normally Black, Transmissive |
| Support Color | 16.7M/1.06B 100%sRGB |
| Light Source | EEFL, 50K hours, With Inverter |
| Weight | 5.50/6.00Kgs (Typ./Max.) |
| Designed For | TV Sets |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (2 ch, 8/10-bit), 51 pinsConnector |
| Power Supply | 12.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 60 °C |
| LC320WUN-SCB1 51 Pins 1920*1080 60Hz LCD Screen for TV Sets | |
LC320WUN-SCB1 LCD Display - Extremely Important Information:
Matching Specifications: It is crucial to match the resolution, backlight, and screen size of the replacement screen with your current screen. Any deviation from your current screen specifications may result in incompatibility with your system.
Contact for Assistance: If you are unsure about the specifications of your current screen, please don't hesitate to contact us. Our team will gladly assist you in determining the correct specifications to ensure compatibility with your system.
100% Compatibility Guarantee: Rest assured, you will receive a replacement screen that is 100% compatible with your system. However, please note that the exact brand and part number of the screen you receive may vary based on market availability. Regardless, the replacement screen will meet the necessary specifications for seamless integration with your device.
For further inquiries or assistance regarding screen compatibility, please reach out to our customer support team. We are committed to ensuring that you receive the correct replacement screen for your needs.
LC320WUN-SCB1 LCD Panel Shipping and Package :
LC320WUN-SCB1 LCD Display SHIPPING :
We use ALI stander shipping EMS DHL fedex and so on. you can choose when you place order .
The items will be sent within 1-2 business days after payment is completed.(some products need more days accounding to the stock )
Each order will be attached a tracking number and we will send to you.
LC320WUN-SCB1 LCD Display Warranty:
Warranty Duration: The warranty period is guaranteed for 3 months from the date of purchase.
Product Replacement: In the event of receiving counterfeit or fake products, we offer a replacement with new and genuine items.
However, it is imperative to ensure that the returned product is unused and free from any man-made damages.
Return Shipping Conditions: Customers are required to ship the product back to us using appropriate packaging to prevent any damages during the return transit.
Quality Assurance: Rest assured, each product undergoes thorough testing before shipment. We ensure that every unit is in optimal working condition, with a 100% guarantee of functionality prior to dispatch.
LC320WUN-SCB1 LCD Panel FAQ :
Q: Can you give me a discount if I need a large quantity of LC320WUN-SCB1 ?
A: Of course!If you make a large order, we will give you a discount.
Q: If I place order now,when will you ship the goods of LC320WUN-SCB1 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Can You declare my order of LC320WUN-SCB1 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How can I trace my order of LC320WUN-SCB1 ?
A: we will give you tracking number then you can trace your order from website.
