32.0 inch 1366(RGB)×768 LM315TU3A TFT LCD Panel LCD Display Module
LM315TU3A Product details :
| PANDA LCD Screen LM315TU3A |
| Manufacturer | PANDA |
| Model Name | LM315TU3A |
| Screen Size | 32.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 1366(RGB)×768 (WXGA) 49PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 697.685 × 392.256 (H×V) |
| Outline(mm) | 725.2 × 421.9 (H×V×D) |
| Bezel Area(mm) | 705.4 × 400.0 (H×V) |
| Treatment | Antiglare, Hard coating (2H) |
| Luminance | 350 cd/m² (Typ.) |
| Contrast Ratio | 5000 : 1 (Typ.) (TM) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Response | 7.0 (Typ.)(G to G) ms |
| Good View at | Symmetry |
| Work Mode | UV2A, Normally Black, Transmissive |
| Color Depth | 16.7M 72% NTSC |
| Backlight | 4 strings WLED , 30K hours , No Driver |
| Mass | 5.50/6.00Kgs (Typ./Max.) |
| Used for | TV Sets |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 8-bit) , Connector 30 pins |
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| 32.0 inch 1366(RGB)×768 LM315TU3A TFT LCD Panel LCD Display Module |
LM315TU3A Attention:
1. Please confirm your machine model and screen model before purchasing, and provide the seller with all the data about your own LCD screen as much as possible, so that the seller can provide a suitable LCD screen. When the product picture is different from your actual screen, please consult the owner to confirm before shipping.
2. Since the LCD screens are all universal, the same machine is of different brands, if the customer has no special requirements, they are all made universal, and the screens are all original products. As long as the LCD screen specifications are the same, many models of LCD screens of different brands are common. And usually the LCD screen used in a notebook is not a designated model, please contact the customer service staff for specific detailed requirements, thank you for your cooperation!
3. There are many models of laptop LCD screens. For the same model of machine, such as Lenovo Y450, it can use LP140WH1, TLN140AT07, B140XW01, etc. These specifications and parameters are the same, and they can all be used. The difference is that the brands are different. We will communicate with you about the specific screen brand before purchasing. The received screen may be a bit different from the screen of your original laptop model, but the screen is compatible and can be used normally.
4. Before installing the screen, please turn off the laptop, disconnect the power supply and remove the battery. Do not install the screen while the laptop is on, otherwise your cable may be burned out.
LM315TU3A NOTE:
Before you ordered , in case of any mistake & trouble in our business , please mail us as below information for double confirming to win this deal together.
•1-->LCD model name in your hand now ,such as : LM315TU3A
•2-->Your laptop name ,such as : DV3000 ......
•3-->Send above information to our mail and we will response you within 24 hours for quick and right deal ,thanks !
LM315TU3A Shipping and Package :
LM315TU3A Delivery:
1.We can send out the items within 7 working days after payment confirmation.
2.The shipping way depends on the shipping cost which you choose, so please choose a proper shipping way according to your own situation.
3.If your place are located in a remote area, it may cost some extra charges, and we would let you know if the shipping cost is changed.
LM315TU3A Shipment:
All items will be shipped within 48 hours after payment verification.
Free of charge: EMS DHL UPS, all tracking numbers of Singore, Hong Kong Post, China
1. For good customers, we declare $10 for each screen.
2. All mail usually takes 20-30 working days to deliver, but we can't guarantee it, sometimes more.
3. If you do not receive your goods in a limited time, you can check at www.17track.net, obtain logistics information, and send an email to us. During this period, we will check the shipment with our shipping company and reply to you as soon as possible.
4. China Post is the cheapest, and we strongly recommend choosing HK DHL because it is faster. DHL and UPS are the fastest (3-8 days), but may cause tariffs. If this happens, the customer is responsible for paying all tariffs, taxes and import fees.
5. All packages delivered by ordinary post (CN Post Hong Kong, SG Post) are limited to 2 kg. Therefore, if your package is overweight, we will arrange for your package to be delivered by 2 packages.
LM315TU3A Other Policies:
1: We are not responsible for any custom duty or import tax.
2: All emails will be answered within 24 hours. If you don’t receive our reply, please kindly re-sent your email and we will reply to you asap.
LM315TU3A FAQ:
Q: I do not find the LCD I am looking for in the website, what should I do ?
A: You can give us some pictures,we have a lot of LCD out of shelves.
Q: How long will I receive my goods of LM315TU3A ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How to make payment for LM315TU3A ?
A: We accept T/T , Paypal , western union .
Q: What happen if the LM315TU3A I receive can't work ?
A: The LM315TU3A will be tested strictly before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
