CC430LV1D LCD Screen Display Panel 43" RGB 1920×1080 FHD 51PPI
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | PANDA |
| Model Number: | CC430LV1D |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | CC430LV1D | Panel Size: | 43" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD, 51PPI | Display Area: | 940.896(W)×529.254(H) Mm |
| Outline Size: | 950.896(W)×541.75(H)×1.37(D) Mm | Driver IC: | COF Built-in 6 Source Chips |
| Panel Weight: | 1.54Kgs (Typ.) | Application: | TV Sets |
| Highlight: | CC430LV1D LCD Screen Display Panel,51PPI LCD Screen Display Panel |
||
Product Description
Brand New Original CC430LV1D LCD Screen Panel In Stock
CC430LV1D Product details :
| PANDA LCD Screen CC430LV1D | |
| Brand | PANDA |
| Model | CC430LV1D |
| Diagonal Size | 43 inch |
| Type | Oxide TFT-LCD, CELL |
| Pixel Format | 1920(RGB)×1080 [FHD] 51PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 940.896(H)×529.254(V) mm |
| Outline Dim. | 950.896(H)×541.75(V)×1.37(D) mm |
| Treatment | Antiglare, Hard coating (2H) |
| Luminance | 0 cd/m² |
| Contrast Ratio | 5000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 8 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Operating Mode | UV2A, Normally Black, Transmissive |
| Plate Thickness | 0.50+0.50 mm |
| Transmittance | 6.3% (Typ.)(with Polarizer) |
| Support Color | 16.7M 77% DCI-P3 |
| Light Source | No B/L |
| Weight | 1.54Kgs (Typ.) |
| Designed For | TV Sets |
| Driver IC | COF Built-in 6 source chips |
| Signal Interface | LVDS (2 ch, 8-bit) , 51 pins Connector |
| Input Voltage | 12.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Brand New Original CC430LV1D LCD Screen Panel In Stock | |
CC430LV1D About Payment Information:
We accept Escrow service.
CC430LV1D About Customs Duty & Handling Fee:
For all customers` orders, we do not charge handing fee, even 1pcs part.
When parts arrive at your local custom, if the parts were charged customs duty, we are not responsible for any customs duties or import taxes.
CC430LV1D Shipping and Package :
CC430LV1D Terms of Shipment:
Before ordering please contact us to confirm your preferred shipment method. Items are only shipped after payment is confirmed by Escrow.
CC430LV1D Shipping Companies:
We support shipment by "EMS" "DHL" "China Post Air Mail ",
If you need help selecting a fast and reliable shipping company, please contact us direct and we will do our best to help.
CC430LV1D Replacement & Refund:
1. We provide 90 days for quality warranty
2. If the parts you purchase from us are not of perfected quality or they don't work, please simply return them to us for replacement or refund
3. If the part is defective, please notify us within 3 days after arrival.
4. Any parts must be returned in their original condition to qualify for a refund or replacement
CC430LV1D Warranty :
1, We take 12 months warranty from the shipping date , no matter what quality problem it's .
2, Pls keep in touch with us , if you have any problems pls contact us immediately , we will help you to solve the problem ASAP. .
CC430LV1D FAQ:
Q: Can I pay my goods CC430LV1D by credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How can I trace my order of PANDA CC430LV1D ?
A: we will give you tracking number then you can trace your order form website.
Q: How long will I receive my goods of CC430LV1D ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: Can you give me a discount if I need a large quantity of PANDA CC430LV1D ?
A: Of course!If you make a large order, we will give you a discount.
