T260XW02 VB 30 Pins 26 Inch LCD Screen 1366*768 for AUO
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | T260XW02 VB |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | T260XW02 VB | Screen Size: | 26.0 Inch |
|---|---|---|---|
| Pixel Number: | 1366(RGB)×768, WXGA, 60PPI | Active Area(mm): | 575.769(W)×323.712(H) Mm |
| Bezel Area(mm): | 580.0(W)×328.8(H) Mm | Viewing Angle: | 85/85/85/85 (Typ.)(CR≥10) |
| Display Colors: | 16.7M 72% NTSC | Used For: | TV Sets |
Product Description
T260XW02 VB 30 Pins 26 Inch LCD Screen 1366*768 for AUO
T260XW02 VB Product details :
| AUO LCD SCREEN T260XW02 VB | |
| Panel Brand | AUO |
| Panel Model | T260XW02 VB |
| Panel Size | 26.0" |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1366(RGB)×768, WXGA, 60PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 575.769(W)×323.712(H) mm |
| Bezel Opening | 580.0(W)×328.8(H) mm |
| Outline Size | 626(W)×373(H) mm |
| Surface | Antiglare (Haze 13%), Hard coating (3H) |
| Brightness | 500 cd/m² (Typ.) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | VA, Normally Black, Transmissive |
| Response Time | 21/4 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| Display Colors | 16.7M 72% NTSC |
| Lamp Type | 14 pcs CCFL , 50K hours , With Inverter |
| Frequency | 60Hz |
| Designed For | TV Sets |
| Touch Screen | Without |
| Panel Weight | 4.50Kgs (Max.) |
| Signal Interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Input Voltage | 12.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| T260XW02 VB 30 Pins 26 Inch LCD Screen 1366*768 for AUO | |
T260XW02 VB Shipment:
When you place an order, please choose a shipping method and pay for the order including the shipping fee. We will send the items within 3 days once your payment is completed.We do not uarantee delivery time on all international shipments due to differences in customs clearing times in individual countries, which may affect how quickly your product is inspected.
T260XW02 VB Payment:
1.- Please make sure your payment account is available before you bid the item.
2.- All payments should be cleared within 7days after you receive the item. If you really have difficulty in paying the item,please contact us firstly, we will help to solve it.
3.- If you have any special request about the details of item, please leave a note in your order.
T260XW02 VB Shipping Information:
We ship to worldwide by DHL,UPS,FEDEX,TNT,EMS ,Normal airmail and agency. It depends on buyer’s requirements.
Delivery Time: We will ship the items within 2 working days after receive the payment.
T260XW02 VB Returns:
We do our best to serve our customers the best that we can.We will refund you if you return the items within 15 days of your receipt of the items for any reason. However, the buyer should make sure that the items returned are in their original conditions. If the items are damaged or lost when they are returned, the buyer will be responsible for such damage or loss, and we will not give the buyer a full refund.The buyer should try to file a claim with the logistic company to recover the cost of damage or loss.
T260XW02 VB FAQ:
Q: How long will I receive my goods T260XW02 VB ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: If I place order now,when will you ship the goods of T260XW02 VB ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Do you accept sample orders of T260XW02 VB ?
A: Of course!sample order is welcome !
Q: How long is the warranty ?
A: We offer 90days warranty .
T260XW02 VB Shippment & Packing
