20.1 Inch AUO LCD Screen 800x600 A201SN01 V5 50 Pins Hard Coating
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | A201SN01 V5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model P/N: | A201SN01 V5 | Diagonal Size: | 20.1" |
|---|---|---|---|
| Resolution: | 800(RGB)×600, SVGA, 49PPI | Active Area: | 408(W)×306(H) Mm |
| Contrast Ratio: | 500:1 (Typ.) (TM) | Response Time: | 5/11 (Typ.)(Tr/Td) Ms |
| Support Color: | 16.2M, 75% NTSC | Designed For: | TV Sets |
| Highlight: | 20.1 inch AUO LCD Screen,A201SN01 V5 AUO LCD Screen |
||
Product Description
20.1 inch 800x600 A201SN01 V5 50 PINS LCD SCREEN
A201SN01 V5 Product details :
| AUO LCD SCREEN A201SN01 V5 | |
| Panel Brand | AUO |
| Model Name | A201SN01 V5 |
| Screen size | 20.1 inches |
| Screen type | a-Si TFT-LCD, LCD module |
| Resolution | 800(RGB)×600, SVGA, 49PPI |
| Pixel | RGB triangle |
| Display size | 408(W)×306(H) mm |
| Outline Size | 448(W)×347(H) mm |
| Visual size | 413.0(W)×311.0(H) mm |
| Surface | Hard coating, Antireflection |
| Brightness | 500 cd/m² (Typ.) |
| Contrast | 500:1 (Typ.) (TM) |
| Optical mode | TN, normally white display, transmissive |
| Viewing angle | 80/80/60/60 (Typ.)(CR≥10) |
| Responding | 5/11 (Typ.)(Tr/Td) ms |
| Number of | 16.2M, 75% NTSC |
| Backlight type | 6 pcs CCFL, 50K hours, without driver |
| Screen weight | 3.50Kgs |
| Apply to | TV Sets |
| Refresh rate | 60Hz |
| Touch function | No touch |
| Signal system | TTL (1 ch, 8-bit), 50 pins, connector |
| Supply voltage | 5.0V (Typ.) |
| Maximum | Working: 0 ~ 50 °C; Storage: -20 ~ 70 °C |
| 20.1 inch 800x600 A201SN01 V5 50 PINS LCD SCREEN | |
A201SN01 V5 Purchase Notice:
- We offer a variety of brands of 1.4-88 inch LCD screens, if you need other displays, you can consult customer service.
- Many original LCD screens have been discontinued and we sell used products in good condition. We do 100% rigorous testing on our displays before delivery. Some products are also available with brand new screens.Please contact customer service before purchasing and we will answer you or give you more accurate information about the display.
- If you are not sure if the product is what you need or if you need more products,please contact me before ordering. We have technical supply and can provide you with technical advice Please send your RFQ(Request for Quotation) to get the latest information price.
A201SN01 V5 Shipment:
When you place an order, please choose a shipping method and pay for the order including the shipping fee. We will send the items within 3 days once your payment is completed.We do not uarantee delivery time on all international shipments due to differences in customs clearing times in individual countries, which may affect how quickly your product is inspected.
A201SN01 V5 FAQ:
Q: How do you ship my goods A201SN01 V5 ?
A: We can shipping all over the world.via DHL,UPS,Fedex and EMS, the packaging is very safe and strong.
Q: Are you manufactory or trade company ?
A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
Q: Can You declare my order of lcd display screen A201SN01 V5 at a very low value ?
A: Yes , we can . pls inform us before shipping .
Q: How long is the warranty of A201SN01 V5 ?
A: 90 days warranty .
A201SN01 V5 Shipping and Package :
