1024x768 IPS Industrial LCD Panel Display G150XTN06.0 15''
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | AUO |
| Model Number: | G150XTN06.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Manufacturer: | AUO | Model Name: | G150XTN06.0 |
|---|---|---|---|
| Screen Size: | 15.0 Inch | Resolution: | 1024(RGB)×768 [XGA] 85PPI |
| Screen Type: | A-Si TFT-LCD, LCD Module | Display Size: | 304.128(H)×228.096(V) Mm |
| Physical Dimension: | 326.5(H)×253.5(V) ×12.5(D) Mm | Visual Size: | 307.4(H)×231.3(V) Mm |
| Luminanceration: | 450cd/m² (Typ.) | Contrast Ratio: | 800:1 (Typ.) (transmission) |
| Responding Time: | 5.7/2.3 (Typ.)(Tr/Td) Ms | Used For: | Industrial |
| High Light: | 768 IPS Industrial LCD Panel Display,1024 IPS Industrial LCD Panel Display,768 IPS G150XTN06.0 15 inch lcd panel |
||
Product Description
15 inch Industrial LCD Panel Display G150XTN06.0 1024*768
Product details :
TFT LCD Panel, LCD/LED backlight
A Grade , 100% New Original
In Stock
| AUO LCD SCREEN G150XTN06.0 | |
| Panel Brand | AUO |
| Panel Model | G150XTN06.0 |
| Panel Size | 15.0 inch |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1024(RGB)×768 [XGA] 85PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 304.128(H)×228.096(V) mm |
| Outline Dim. | 326.5(H)×253.5(V) ×12.5(D) mm |
| Bezel Area | 307.4(H)×231.3(V) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 450 cd/m² (Typ.) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Response Time | 5.7/2.3 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/70/80 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 262K/16.2M 60% NTSC |
| Light Source | WLED , 50K hours , With LED Driver |
| Weight | 1.00Kgs (Max.) |
| Designed For | Industrial |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
|
15 inch Industrial LCD Panel Display G150XTN06.0 1024*768 |
|
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
FAQ :
Q: Can You declare my order of G150XTN06.0 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: Can I pay my order of G150XTN06.0 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How to make payment of G150XTN06.0 ?
A: We accept T/T , Paypal , western union .
Q: How can I trace my order of G150XTN06.0 ?
A: we will give you tracking number then you can trace your order from website.
We are one of the professional and experienced suppliers of 15 inch Industrial LCD Panel Display G150XTN06.0 1024*768, offering you the quotation and the price list consultation. Welcome to wholesale the high-end, quality and low price products in stock with us. Good after-sale service and fast delivery are available.
*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
