New 1280*800 N154I3-P03 15.4 inch 60Hz LCD Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | CMO |
| Model Number: | N154I3-P03 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | N154I3-P03 | Diagonal Size: | 15.4" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, CELL, FOB | Resolution: | 1280(RGB)×800, WXGA 98PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 331.2(W)×207(H) Mm |
| Touch Panel: | Without | Used For: | Laptop |
| Highlight: | 40.0 inch LCD Panel,V400DK1-KE1 LCD Panel,120Hz LCD Panel |
||
Product Description
New 1280*800 N154I3-P03 15.4 inch 60Hz LCD Panel
N154I3-P03 LCD Panel Product details :
| Brand | CMO |
| Model P/N | N154I3-P03 |
| Diagonal Size | 15.4" |
| Panel Type | a-Si TFT-LCD, CELL, FOB |
| Resolution | 1280(RGB)×800, WXGA 98PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 331.2(W)×207(H) mm |
| Bezel Opening | - |
| Outline Dim. | 339.7(H)×216.16(V)×1.43(D) mm |
| Treatment | Glare (Haze 0%), Hard coating (3H) |
| Luminance | 0 cd/m² |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| View Direction | - |
| Response Time | 3/5 (Typ.)(Tr/Td) |
| Viewing Angle | 45/45/20/45 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Plate Thickness | 0.50+0.50 mm |
| Transmittance | 8.0% (Typ.)(with Polarizer) |
| Support Color | 262K 43%NTSC |
| Light Source | No B/L |
| Form Style | - |
| Designed For | Laptop |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| D-IC Detail | Built-in 6 source COF + 3 gate COG chips |
| Interface Type | LVDS (1 ch, 6-bit), 30 pinsConnector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
N154I3-P03 LCD Panel Note :
Model Verification:
Please ensure that the model number you need is exactly the same as the model number you have ordered. We will ship the LCD panel based strictly on the model specified in your order. Ensuring the correct model number is crucial to avoid any compatibility issues.
Comprehensive Testing:
We conduct 100% testing on each LCD panel to ensure it meets our stringent quality standards. This thorough testing process guarantees that you receive a fully functional and reliable product. Our commitment to quality ensures that each panel is meticulously checked before it is shipped to you.
N154I3-P03 LCD Panel Shipping and Package :
N154I3-P03 LCD Panel Shipping Guidelines:
Address Confirmation:
It is crucial to verify that the shipping address provided in your order is accurate. We will ship the LCD panel to the address listed in the order. If you need the panel to be shipped to a different address, please email us the new address immediately after making the payment to avoid any shipping errors.
Shipment Timeline:
Your order will be processed and shipped within three business days after we have received your payment. Please note that business days do not include weekends or public holidays, so take this into account when estimating your delivery date.
N154I3-P03 LCD Panel ESTIMATED DELIVERY TIME :
Standard Shipping:
The estimated delivery time for standard shipping is between 10 to 35 working days. This timeframe may vary depending on the destination and other factors such as customs processing and local postal services.
Expedited Shipping:
For a faster delivery option, expedited shipping is available with an estimated delivery time of 4 to 7 working days. This option is ideal if you need the LCD panel urgently and prefer a quicker shipping method.
N154I3-P03 LCD Panel FAQ :
Q: If I place order now,when will you ship the goods N154I3-P03 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Can you give me a discount if I need a large quantity N154I3-P03 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How long will I receive my goods N154I3-P03 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How to make payment N154I3-P03 ?
A: We accept T/T , Paypal , western union .
