• 21.6 Inch 1920*1080 M216H1-P01 LCD Screen Panel
21.6 Inch 1920*1080 M216H1-P01 LCD Screen Panel

21.6 Inch 1920*1080 M216H1-P01 LCD Screen Panel

Product Details:

Place of Origin: China
Brand Name: Innolux
Model Number: M216H1-P01

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: Negotiable
Packaging Details: Original packaging/conventional packaging box
Delivery Time: 7 Days
Payment Terms: T/T, Western Union
Supply Ability: 100000 Unit/Units per Month
Get Best Price Contact Now

Detail Information

Model Name: M216H1-P01 Diagonal Size: 21.6"
Panel Type: A-Si TFT-LCD, CELL, FOB Resolution: 1920(RGB)×1080, FHD 102PPI
Pixel Format: RGB Vertical Stripe Active Area: 477.504(W)×268.596(H) Mm
Touch Panel: Without Used For: Desktop Monitor
Highlight:

40.0 inch LCD Screen

,

3840*2160 LCD Screen

,

V400DJ1-KS5 LCD Screen

Product Description

21.6 Inch 1920*1080 M216H1-P01 LCD Screen Panel



M216H1-P01 LCD Panel Product details :



Brand CMO
Model P/N M216H1-P01
Diagonal Size 21.6"
Panel Type a-Si TFT-LCD, CELL, FOB
Resolution 1920(RGB)×1080, FHD 102PPI
Pixel Format RGB Vertical Stripe
Active Area 477.504(W)×268.596(H) mm
Bezel Opening -
Outline Dim. 488.954(H)×280.096(V)×1.83(D) mm
Treatment Antiglare (Haze 25%), Hard coating (3H)
Luminance 0 cd/m²
Contrast Ratio 1000:1 (Typ.) (TM)
View Direction 6 o'clock
Response Time 1.3/3.7 (Typ.)(Tr/Td)
Viewing Angle 85/85/80/80 (Typ.)(CR≥10)
Operating Mode TN, Normally White, Transmissive
Plate Thickness 0.70+0.70 mm
Transmittance 5.2% (Typ.)(with Polarizer)
Support Color 16.7M 68%NTSC
Light Source No B/L, W/O Driver
Weight 600g (Max.)
Designed For Desktop Monitor
Frame Rate 60Hz
Touch Panel Without
D-IC Detail COG Built-in 8 source COF + 4 gate COG chips
Interface Type LVDS (2 ch, 8-bit), 30 pinsConnector
Power Supply 5.0V (Typ.)
Environment Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

M216H1-P01 LCD Panel Note :

Model Verification:
Please ensure that the model number you need is exactly the same as the model number you have ordered. We will ship the LCD panel based strictly on the model specified in your order. Ensuring the correct model number is crucial to avoid any compatibility issues.

Comprehensive Testing:
We conduct 100% testing on each LCD panel to ensure it meets our stringent quality standards. This thorough testing process guarantees that you receive a fully functional and reliable product. Our commitment to quality ensures that each panel is meticulously checked before it is shipped to you.


M216H1-P01 LCD Panel Shipping and Package :

21.6 Inch 1920*1080 M216H1-P01 LCD Screen Panel 0

M216H1-P01 LCD Panel Shipping Guidelines:

Address Confirmation:
It is crucial to verify that the shipping address provided in your order is accurate. We will ship the LCD panel to the address listed in the order. If you need the panel to be shipped to a different address, please email us the new address immediately after making the payment to avoid any shipping errors.

Shipment Timeline:
Your order will be processed and shipped within three business days after we have received your payment. Please note that business days do not include weekends or public holidays, so take this into account when estimating your delivery date.

M216H1-P01 LCD Panel ESTIMATED DELIVERY TIME :

Standard Shipping:
The estimated delivery time for standard shipping is between 10 to 35 working days. This timeframe may vary depending on the destination and other factors such as customs processing and local postal services.

Expedited Shipping:
For a faster delivery option, expedited shipping is available with an estimated delivery time of 4 to 7 working days. This option is ideal if you need the LCD panel urgently and prefer a quicker shipping method.


M216H1-P01 LCD Panel FAQ :



Q: If I place order now,when will you ship the goods of M216H1-P01 ?

A: The order will be shipped within 2-3 working days after received your payment.



Q: Can you give me a discount if I need a large quantity of M216H1-P01 ?

A: Of course!If you make a large order, we will give you a discount.



Q: How long will I receive my goods M216H1-P01 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.



Q: How to make payment of M216H1-P01 ?

A: We accept T/T , Paypal , western union .
