N089L6-L02 Rev.C2 8.9 inch 40 pins LCD Screen Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | CMO |
| Model Number: | N089L6-L02 Rev.C2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | N089L6-L02 Rev.C2 | Diagonal Size: | 8.9" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 1024(RGB)×600, WSVGA 133PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 195.072(W)×113.4(H) Mm |
| Touch Panel: | Without | Used For: | Netbook PC |
| Highlight: | V320BJ6-Q01 Rev.C2 LCD Screen Panel,32.0 inch LCD Screen Panel,30 pins LCD Screen Panel |
||
Product Description
N089L6-L02 Rev.C2 8.9 inch 40 pins LCD Screen Panel
N089L6-L02 Rev.C2 LCD Panel Product details :
| Brand | CMO |
| Model P/N | N089L6-L02 Rev.C2 |
| Diagonal Size | 8.9" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1024(RGB)×600, WSVGA 133PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 195.072(W)×113.4(H) mm |
| Bezel Opening | 198.27(W)×116.6(H) mm |
| Outline(mm) | 213.36(W)×129.55(H)×5.45(D) |
| Luminance | 200 (Typ.)(cd/m²) |
| Viewing Angle | 45/45/20/45 (Typ.)(CR≥10) |
| Good View at | 6 o'clock |
| Color Depth | 262K 45% NTSC |
| Outline Shape | - |
| Refresh Rate | 60Hz |
| Treatment | Glare (Haze 0%), Hard coating (3H) |
| Contrast Ratio | 400 : 1 (Typ.) (TM) |
| Work Mode | TN, Normally White, Transmissive |
| Response | 3/7 (Typ.)(Tr/Td) ms |
| Backlight | 9S3P WLED , 15K hours , With LED Driver |
| Used for | Netbook PC |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 6-bit), 40 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
N089L6-L02 Rev.C2 LCD Panel Note :
Model Verification:
Please ensure that the model number you need is exactly the same as the model number you have ordered. We will ship the LCD panel based strictly on the model specified in your order. Ensuring the correct model number is crucial to avoid any compatibility issues.
Comprehensive Testing:
We conduct 100% testing on each LCD panel to ensure it meets our stringent quality standards. This thorough testing process guarantees that you receive a fully functional and reliable product. Our commitment to quality ensures that each panel is meticulously checked before it is shipped to you.
N089L6-L02 Rev.C2 LCD Panel Shipping and Package :
N089L6-L02 Rev.C2 LCD Panel Shipping Guidelines:
Address Confirmation:
It is crucial to verify that the shipping address provided in your order is accurate. We will ship the LCD panel to the address listed in the order. If you need the panel to be shipped to a different address, please email us the new address immediately after making the payment to avoid any shipping errors.
Shipment Timeline:
Your order will be processed and shipped within three business days after we have received your payment. Please note that business days do not include weekends or public holidays, so take this into account when estimating your delivery date.
N089L6-L02 Rev.C2 LCD Panel ESTIMATED DELIVERY TIME :
Standard Shipping:
The estimated delivery time for standard shipping is between 10 to 35 working days. This timeframe may vary depending on the destination and other factors such as customs processing and local postal services.
Expedited Shipping:
For a faster delivery option, expedited shipping is available with an estimated delivery time of 4 to 7 working days. This option is ideal if you need the LCD panel urgently and prefer a quicker shipping method.
N089L6-L02 Rev.C2 LCD Panel FAQ :
Q: How to order lcd panel N089L6-L02 Rev.C2 ?
A: We accept T/T , Paypal , western union .
Q: Can you tested the N089L6-L02 Rev.C2 before shipping ?
A: Of course , lcd screen N089L6-L02 Rev.C2 was Strictly tested before shipping.
Q: What happen if the N089L6-L02 Rev.C2 received can't work ?
A: N089L6-L02 Rev.C2 lcd panel was tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel .
Q: How long the warranty of the N089L6-L02 Rev.C2 ?
A: 90 days .
