N089L6-L01 8.9 Inch 1024*600 LVDS LCD Screen LCD Module
Product Details:
| Place of Origin: | China |
| Brand Name: | CMO |
| Model Number: | N089L6-L01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | N089L6-L01 | Diagonal Size: | 8.9" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 1024(RGB)×600, WSVGA 133PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 195.072(W)×113.4(H) Mm |
| Frame Rate: | 60Hz | Used For: | Netbook PC |
| Highlight: | 1366*768 LCD Screen,29.0 inch LCD Screen,V290BJ1-PE2 LCD Screen |
||
Product Description
N089L6-L01 8.9 Inch 1024*600 LVDS LCD Screen LCD Module
N089L6-L01 LCD Panel Product details :
| Brand | CMO |
| Model P/N | N089L6-L01 |
| Diagonal Size | 8.9" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1024(RGB)×600, WSVGA 133PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 195.072(W)×113.4(H) mm |
| Bezel Opening | 198.27(W)×116.6(H) mm |
| Outline Size | 213.36(W)×129.55(H)×5.45(D) mm |
| Surface | Antiglare, Hard coating (3H) |
| Brightness | 200 cd/m² (Typ.) |
| Contrast Ratio | 400:1 (Typ.) (TM) |
| Viewing Angle | 80/80/70/70 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | - |
| Response Time | 3/7 (Typ.)(Tr/Td) |
| Display Colors | 262K 45%NTSC |
| Lamp Type | 9S3PWLED, 15K hours, With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Shape Style | - |
| Application | Netbook PC |
| Signal Interface | LVDS (1 ch, 6-bit), 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C |
