P070ACB-DB1 7.0 inch LCD Screen display for Pad Tablet
Product Details:
| Place of Origin: | China |
| Brand Name: | Innolux |
| Model Number: | P070ACB-DB1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | P070ACB-DB1 | Diagonal Size: | 7.0" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, Assembly | Resolution: | 600(RGB)×1024, WSVGA 170PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 89.28(W)×152.37(H) Mm |
| Designed For: | Pad & Tablet | Touchscreen: | On-Cell Touch, I²C |
Product Description
P070ACB-DB1 7.0 inch LCD Screen display for Pad Tablet
P070ACB-DB1 LCD Panel Product details :
| Brand | Innolux |
| Model P/N | P070ACB-DB1 |
| Diagonal Size | 7.0" |
| Panel Type | a-Si TFT-LCD, Assembly |
| Resolution | 600(RGB)×1024, WSVGA 170PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 89.28(W)×152.37(H) mm |
| Bezel Opening | - |
| Outline Size | 95(W)×163.27(H)×4.15(D) mm |
| Surface | Hard coating (7H) |
| Brightness | 300 cd/m² (Typ.) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | IPS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Display Colors | 16.7M 50%NTSC |
| Lamp Type | 6S3PWLED, Without Driver |
| Frequency | 60Hz |
| Touch Screen | On-Cell Touch, I²C |
| Panel Weight | 125g (Typ.) |
| Application | Pad & Tablet |
| Signal Interface | MIPI (4 data lanes), 39 pinsConnector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -20 ~ 70 °C |
| P070ACB-DB1 7.0 inch LCD Screen display for Pad Tablet | |
