HOT SELL 17.3 inch N173DSE-G3A 40 pins LCD Screen
Product Details:
Place of Origin: | China |
Brand Name: | Innolux |
Model Number: | N173DSE-G3A |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Original packaging/conventional packaging box |
Delivery Time: | 7 Days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 100000 Unit/Units per Month |
Detail Information |
|||
Model Name: | N173DSE-G3A | Diagonal Size: | 17.3" |
---|---|---|---|
Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 3840(RGB)×2160, UHD 255PPI |
Pixel Format: | RGB Vertical Stripe | Active Area: | 381.888(W)×214.812(H) Mm |
Touch Panel: | Without | Designed For: | Laptop |
Product Description
HOT SELL 17.3 inch N173DSE-G3A 40 pins LCD Screen
N173DSE-G3A LCD Panel Product details :
Brand | Innolux |
Model P/N | N173DSE-G3A |
Diagonal Size | 17.3" |
Panel Type | a-Si TFT-LCD, LCM |
Resolution | 3840(RGB)×2160, UHD 255PPI |
Pixel Format | RGB Vertical Stripe |
Active Area | 381.888(W)×214.812(H) mm |
Bezel Opening | - |
Outline(mm) | 399.5(W)×246.51(H)×4(D) |
Luminance | 300 (Typ.)(cd/m²) |
Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
Good View at | Symmetry |
Color Depth | 16.7M |
Outline Shape | - |
Refresh Rate | 60Hz |
Treatment | Antiglare (Haze 24%), Hard coating (3H) |
Contrast Ratio | 800 : 1 (Typ.) (TM) |
Work Mode | AAS, Normally Black, Transmissive |
Response | 14/11 (Typ.)(Tr/Td) ms |
Backlight | WLED , 15K hours , With LED Driver |
Used for | Laptop |
Touchscreen | Without |
Signal Type | eDP (4 Lanes), 40 pins Connector |
Voltage Supply | 3.3V (Typ.) |
Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
HOT SELL 17.3 inch N173DSE-G3A 40 pins LCD Screen |
N173DSE-G3A LCD Panel Shipping and Package :
N173DSE-G3A LCD Panel FAQ :
Q: Are you manufactory or trade company?
A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
Q: Can you declared low value for my order when shipping?
A: Yes, We can do it for you if you need.
Q: How to do if I can't find the screen that I require in your listings?
A: We should have it in stock , please contact us directly.if we dont't have it , we can try our best to find it for you .
Q: Why big order delivery time are long?
A: All the lcd panel are Strictly tested before shipment , to ensure that you receive good quality lcd panel and work well!
