55.0 inch S550HJ1-Q02 1920*1080 LCD screen Panel display
Product Details:
| Place of Origin: | China |
| Brand Name: | Innolux |
| Model Number: | S550HJ1-Q02 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | S550HJ1-Q02 | Diagonal Size: | 55.0" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, CELL, FOB | Resolution: | 1920(RGB)×1080, FHD 40PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 1209.6(W)×680.4(H) Mm |
| Used For: | Video Wall | Touch Screen: | Without |
Product Description
55.0 inch S550HJ1-Q02 1920*1080 LCD screen Panel display
S550HJ1-Q02 LCD Panel Product details :
| Brand | Innolux |
| Model P/N | S550HJ1-Q02 |
| Diagonal Size | 55" |
| Panel Type | a-Si TFT-LCD, CELL, FOB |
| Resolution | 1920(RGB)×1080, FHD 40PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 1209.6(W)×680.4(H) mm |
| Bezel Opening | - |
| Outline Size | 1212.65(W)×683.45(H)×1.33(D) mm |
| Brightness | 0 cd/m² |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Glass Depth | 0.50+0.50 mm |
| Display Colors | 16.7M 71%NTSC |
| Frequency | 60Hz |
| Videowall Seam | - |
| Surface | Antiglare (Haze 44%), Hard coating (3H) |
| Contrast Ratio | 4000:1 (Typ.) (TM) |
| Display Mode | Super MVA, Normally Black, Transmissive |
| Response Time | 9.5 (Typ.)(G to G) |
| Transmissivity | 6.2% (Typ.)(with Polarizer) |
| Lamp Type | No B/L |
| Touch Screen | Without |
| Application | Video Wall |
| Driver IC | COFBuilt-in 16 source + 8 gate chips |
| Signal Interface | LVDS (2 ch, 8-bit), 51 pinsConnector |
| Input Voltage | 12.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C |
| 55.0 inch S550HJ1-Q02 1920*1080 LCD screen Panel display | |
S550HJ1-Q02 LCD Panel Shipping and Package :
S550HJ1-Q02 LCD Panel FAQ :
Q: What happen if the lcd panel S550HJ1-Q02 I received can't work ?
A: All the goods will be tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
Q: How to do if I can't find the screen that I require in your listings?
A: We should have it in stock , please contact us directly.if we dont't have it , we can try our best to find it for you .
Q: Why big order delivery time are long?
A: All the lcd panel are Strictly tested before shipment , to ensure that you receive good quality lcd panel and work well!
Q:Can you declared low value for my order when shipping?
A:Yes, We can do it for you if you need.
