Name: P2130QSF2MA00 21.3 inch 2560*2048 1100 cd/m2 lcd screen
Brand: Shenzhen Yongsheng Innovation Technology Co., Ltd
SKU: P2130QSF2MA00
Availability: InStock

Brand Name:	TIANMA
Model Number:	P2130QSF2MA00
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

P2130QSF2MA00

Diagonal Size:

21.3"

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

2560(RGB)×2048, QSXGA 153PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

422.4(W)×337.92(H) Mm

Used For:

Medical Imaging

Refresh Rate:

60Hz

Supply Ability:

100000 Unit/Units per Month

Product Description

P2130QSF2MA00 21.3 inch 2560*2048 1100 cd/m2 lcd screen

P2130QSF2MA00 LCD Panel Product details :

Brand	TIANMA
Model P/N	P2130QSF2MA00
Diagonal Size	21.3"
Panel Type	a-Si TFT-LCD, LCM
Resolution	2560(RGB)×2048, QSXGA 153PPI
Pixel Format	RGB Vertical Stripe
Active Area	422.4(W)×337.92(H) mm
Bezel Opening	-
Outline Dim.	442.3(H)×354.9(V)×20.9(D)mm
Treatment	Antiglare, Hard coating
Luminance	1100 cd/m² (Typ.)
Contrast Ratio	2000:1 (Typ.) (TM)
View Direction	Symmetry
Response Time	25 (Typ.)(Tr+Td)
Viewing Angle	88/88/88/88 (Typ.)(CR≥10)
Operating Mode	SFT, Normally Black, Transmissive
Support Color	1.07B 72%NTSC
Light Source	WLED, 50K hours, With LED Driver
Weight	2.26Kgs
Designed For	Medical Imaging
Frame Rate	60Hz
Touch Panel	Without
Interface Type	LVDS (4 ch, 10-bit)Connector
Power Supply	12.0V (Typ.)
Environment	Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C
P2130QSF2MA00 21.3 inch 2560*2048 1100 cd/m2 lcd screen

P2130QSF2MA00 LCD Display Features :

High Quality:

Highest quality touch LCD screen replacement parts.

Repair Utility:

Suitable for repairing faulty screens, touch screen problems, dead pixels, cracked touchscreens, and other related issues.

Thorough Testing:

Each assembly is tested before shipping to ensure 100% functionality.

Quality control includes checks for dark spots, color points, and dead pixels, ensuring no defects.

P2130QSF2MA00 LCD Panel Shipping and Package :

P2130QSF2MA00 21.3 inch 2560*2048 1100 cd/m2 lcd screen 0

P2130QSF2MA00 LCD Display Shipping Policy :

Shipping Method:

If the buyer selects a specific courier (e.g., FedEx), we may ship the product using an equivalent service level from other logistics companies such as DHL, UPS, TNT, or others.

Specified Logistics:

If you require a specific logistics company, please inform us in advance.

P2130QSF2MA00 LCD Display Return Policy :

Product Status:

The product's condition (new or old) will be indicated in the product title.

Return and Exchange Conditions:

If the product encounters quality problems within 30 days of receipt, we offer free returns and exchanges.

Return Procedure:

When returning the product, please provide a detailed explanation of the issues encountered.

Include actual photos showing the problems with the product.

P2130QSF2MA00 LCD Panel FAQ :

Q: How can I trace my order of P2130QSF2MA00 ?

A: we will give you tracking number then you can trace your order from website.

Q: If I place order now,when will you ship the goods of P2130QSF2MA00 ?

A: The order will be shipped within 2-3 working days after received your payment.

Q: Do you accept sample orders of P2130QSF2MA00 ?

A: Of course!sample order is welcome !

Q: Can you give me a discount if I need a large quantity of P2130QSF2MA00 ?

A: Of course!If you make a large order, we will give you a discount.
