Name: LAM213X412B 21.3 inch 1600*1200 60Hz lcd panel LCD Module
Brand: Shenzhen Yongsheng Innovation Technology Co., Ltd
SKU: LAM213X412B
Availability: InStock

Brand Name:	JDI
Model Number:	LAM213X412B
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

LAM213X412B

Diagonal Size:

21.3"

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

1600(RGB)×1200, UXGA 94PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

432(W)×324(H) Mm

Used For:

Medical Imaging

Touchscreen:

Without

Supply Ability:

100000 Unit/Units per Month

Product Description

LAM213X412B 21.3 inch 1600*1200 60Hz lcd panel LCD Module

LAM213X412B LCD Panel Product details :

Brand	JDI
Model P/N	LAM213X412B
Diagonal Size	21.3"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1600(RGB)×1200, UXGA 94PPI
Pixel Format	RGB Vertical Stripe
Active Area	432(W)×324(H) mm
Bezel Opening	-
Outline Size	460.6(W)×362(H)×28(D) mm
Surface	Antiglare
Brightness	770 cd/m² (Typ.)
Contrast Ratio	1100:1 (Typ.) (TM)
Viewing Angle	88/88/88/88 (Typ.)(CR≥10)
Display Mode	IPS-Pro, Normally Black, Transmissive
Best View on	Symmetry
Response Time	12/10 (Typ.)(Tr/Td)
Display Colors	16.7M 99%sRGB
Lamp Type	WLED, With LED Driver
Frequency	60Hz
Touch Screen	Without
Panel Weight	3.00/3.40Kgs (Typ./Max.)
Application	Medical Imaging
Signal Interface	LVDS (2 ch, 8-bit), 30 pins Connector
Input Voltage	12.0V (Typ.)
Environment	Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C
LAM213X412B 21.3 inch 1600*1200 60Hz lcd panel LCD Module

LAM213X412B LCD Display Features :

High Quality:

Highest quality touch LCD screen replacement parts.

Repair Utility:

Suitable for repairing faulty screens, touch screen problems, dead pixels, cracked touchscreens, and other related issues.

Thorough Testing:

Each assembly is tested before shipping to ensure 100% functionality.

Quality control includes checks for dark spots, color points, and dead pixels, ensuring no defects.

LAM213X412B LCD Panel Shipping and Package :

LAM213X412B 21.3 inch 1600*1200 60Hz lcd panel LCD Module 0

LAM213X412B LCD Display Shipping Policy :

Shipping Method:

If the buyer selects a specific courier (e.g., FedEx), we may ship the product using an equivalent service level from other logistics companies such as DHL, UPS, TNT, or others.

Specified Logistics:

If you require a specific logistics company, please inform us in advance.

LAM213X412B LCD Display Return Policy :

Product Status:

The product's condition (new or old) will be indicated in the product title.

Return and Exchange Conditions:

If the product encounters quality problems within 30 days of receipt, we offer free returns and exchanges.

Return Procedure:

When returning the product, please provide a detailed explanation of the issues encountered.

Include actual photos showing the problems with the product.

LAM213X412B LCD Panel FAQ :

Q: Why big order delivery time are long?

A: All the lcd panel are Strictly tested before shipment , to ensure that you receive good quality lcd panel and work well!

Q: Are you manufactory or trade company?

A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.

Q: Can you declared low value for my order when shipping?

A: Yes, We can do it for you if you need.

Q: How to do if I can't find the screen that I require in your listings?

A: We should have it in stock , please contact us directly.if we dont't have it , we can try our best to find it for you .
