New 18.1 inch ITSX98E 1280*1024 lcd panel FOR Desktop Monitor
Product Details:
| Place of Origin: | China |
| Brand Name: | IDTech |
| Model Number: | ITSX98E |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | ITSX98E | Diagonal Size: | 18.1" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 1280(LCR)×1024, SXGA 90PPI |
| Pixel Format: | LCR Vertical Stripe | Active Area: | 359.04(W)×287.232(H) Mm |
| Used For: | Desktop Monitor、Medical Imaging | Touchscreen: | Without |
Product Description
New 18.1 inch ITSX98E 1280*1024 lcd panel FOR Desktop Monitor
ITSX98E LCD Panel Product details :
| Brand | IDTech |
| Model P/N | ITSX98E |
| Diagonal Size | 18.1" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1280(RGB)×1024, SXGA 90PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 359.04(W)×287.232(H) mm |
| Bezel Opening | 367.0(W)×295.2(H) mm |
| Outline (mm) | 389×317.2 (H×V×D) |
| Treatment | Antiglare |
| Luminance | 270 cd/m² (Typ.) |
| Contrast Ratio | 400 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Min.)(CR≥10) |
| Response | 40 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | DD-IPS, Normally Black, Transmissive |
| Color Depth | 16.7M 99%sRGB |
| Backlight | 6 pcsCCFL, 50K hours, With Inverter |
| Mass | 2.90Kgs (Typ.) |
| Used for | Desktop Monitor,Medical Imaging |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (2 ch, 8-bit), Connector30 pins |
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| New 18.1 inch ITSX98E 1280*1024 lcd panel FOR Desktop Monitor | |
ITSX98E LCD Panel Shipping and Package :
ITSX98E LCD Panel FAQ :
Q: Are you manufactory or trade company?
A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
Q: Can you declared low value for my order when shipping?
A: Yes, We can do it for you if you need.
Q: How to do if I can't find the screen that I require in your listings?
A: We should have it in stock , please contact us directly.if we dont't have it , we can try our best to find it for you .
Q: Why big order delivery time are long?
A: All the lcd panel are Strictly tested before shipment , to ensure that you receive good quality lcd panel and work well!
