Name: ITSX88E 18.1 inch 1280*1024 30 pins LCD screen lcd panel
Brand: Shenzhen Yongsheng Innovation Technology Co., Ltd
SKU: ITSX88E
Availability: InStock

Brand Name:	IDTech
Model Number:	ITSX88E
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

ITSX88E

Diagonal Size:

18.1"

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

1280(LCR)×1024, SXGA 90PPI

Pixel Format:

LCR Vertical Stripe

Active Area:

359.04(W)×287.232(H) Mm

Used For:

Medical Imaging

Touchscreen:

Without

Supply Ability:

100000 Unit/Units per Month

Product Description

ITSX88E 18.1 inch 1280*1024 30 pins LCD screen lcd panel

ITSX88E LCD Panel Product details :

Brand	IDTech
Model P/N	ITSX88E
Diagonal Size	18.1"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1280(LCR)×1024, SXGA 90PPI
Pixel Format	LCR Vertical Stripe
Active Area	359.04(W)×287.232(H) mm
Bezel Opening	367.0(W)×295.2(H) mm
Outline Dim.	389(W)×317.2(H)×35(D) mm
Treatment	-
Luminance	700 cd/m² (Typ.)
Contrast Ratio	550:1 (Typ.) (TM)
View Direction	Symmetry
Response Time	40 (Typ.)(Tr+Td)
Viewing Angle	85/85/85/85 (Min.)(CR≥10)
Operating Mode	DD-IPS, Normally Black, Transmissive
Support Color	Grayscale
Light Source	CCFL [6 pcs], With Inverter
Weight	2.90Kgs (Typ.)
Designed For	Medical Imaging
Frame Rate	60Hz
Touch Panel	Without
Interface Type	LVDS (2 ch, 8-bit), 30 pinsConnector
Power Supply	12.0V (Typ.)
Environment	Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
ITSX88E 18.1 inch 1280*1024 30 pins LCD screen lcd panel

ITSX88E LCD Display Features :

High Quality:

Highest quality touch LCD screen replacement parts.

Repair Utility:

Suitable for repairing faulty screens, touch screen problems, dead pixels, cracked touchscreens, and other related issues.

Thorough Testing:

Each assembly is tested before shipping to ensure 100% functionality.

Quality control includes checks for dark spots, color points, and dead pixels, ensuring no defects.

ITSX88E LCD Panel Shipping and Package :

ITSX88E 18.1 inch 1280*1024 30 pins LCD screen lcd panel 0

ITSX88E LCD Display Shipping Policy :

Shipping Method:

If the buyer selects a specific courier (e.g., FedEx), we may ship the product using an equivalent service level from other logistics companies such as DHL, UPS, TNT, or others.

Specified Logistics:

If you require a specific logistics company, please inform us in advance.

ITSX88E LCD Display Return Policy :

Product Status:

The product's condition (new or old) will be indicated in the product title.

Return and Exchange Conditions:

If the product encounters quality problems within 30 days of receipt, we offer free returns and exchanges.

Return Procedure:

When returning the product, please provide a detailed explanation of the issues encountered.

Include actual photos showing the problems with the product.

ITSX88E LCD Panel FAQ :

Q: Can You declare my order of ITSX88E a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .

Q: Can you give me a discount if I need a large quantity of ITSX88E ?

A: Of course!If you make a large order, we will give you a discount.

Q: Do you accept sample orders of ITSX88E ?

A: Of course!sample order is welcome !

Q: Can I pay my order of ITSX88E via credit card ?

A: Yes!you can use your credit card through your Paypal account.
