mini 3.5 inch FX0305J1DSSWDG01 LCD screen with Mobile Phone

Brand Name:	Data Image
Model Number:	FX0305J1DSSWDG01
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

FX0305J1DSSWDG01

Diagonal Size:

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

320(RGB)×480, HVGA 166PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

48.96(W)×73.44(H) Mm

Refresh Rate:

Used For:

Mobile Phone

Supply Ability:

100000 Unit/Units per Month

Product Description

mini 3.5 inch FX0305J1DSSWDG01 LCD screen with Mobile Phone

FX0305J1DSSWDG01 LCD Panel Product details :

Brand	Data Image
Model P/N	FX0305J1DSSWDG01
Diagonal Size	3.5"
Panel Type	a-Si TFT-LCD, LCM
Resolution	320(RGB)×480, HVGA 166PPI
Pixel Format	RGB Vertical Stripe
Active Area	48.96(W)×73.44(H) mm
Bezel Opening	49.96(W)×74.44(H) mm
Outline Dim.	55.26(H)×84.69(V)×2.3(D) mm
Treatment	-
Luminance	300 cd/m² (Typ.)
Contrast Ratio	500:1 (Typ.) (TM)
View Direction	-
Response Time	5/15 (Typ.)(Tr/Td)
Viewing Angle	70/70/60/60 (Typ.)(CR≥10)
Operating Mode	TN, Normally White, Transmissive
Support Color	262K 60%NTSC
Light Source	WLED [1S6P], 30K hours, W/O Driver
Weight	19.0g (Typ.)
Designed For	Mobile Phone
Frame Rate	60Hz
Touch Panel	Without
Interface Type	CPU/RGB/SPI, 45 pinsFPC
Power Supply	3.3/3.3V (Typ.)(IOVCC/VCC)
Environment	Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
mini 3.5 inch FX0305J1DSSWDG01 LCD screen with Mobile Phone

FX0305J1DSSWDG01 LCD Panel Note :

Model Verification:

Please ensure that the model number you need is exactly the same as the model number you have ordered. We will ship the LCD panel based strictly on the model specified in your order. Ensuring the correct model number is crucial to avoid any compatibility issues.

Comprehensive Testing:

We conduct 100% testing on each LCD panel to ensure it meets our stringent quality standards. This thorough testing process guarantees that you receive a fully functional and reliable product. Our commitment to quality ensures that each panel is meticulously checked before it is shipped to you.

FX0305J1DSSWDG01 LCD Panel Shipping and Package :

mini 3.5 inch FX0305J1DSSWDG01 LCD screen with Mobile Phone 0

FX0305J1DSSWDG01 LCD Panel Shipping Guidelines:

Address Confirmation:

It is crucial to verify that the shipping address provided in your order is accurate. We will ship the LCD panel to the address listed in the order. If you need the panel to be shipped to a different address, please email us the new address immediately after making the payment to avoid any shipping errors.

Shipment Timeline:

Your order will be processed and shipped within three business days after we have received your payment. Please note that business days do not include weekends or public holidays, so take this into account when estimating your delivery date.

FX0305J1DSSWDG01 LCD Panel ESTIMATED DELIVERY TIME :

Standard Shipping:

The estimated delivery time for standard shipping is between 10 to 35 working days. This timeframe may vary depending on the destination and other factors such as customs processing and local postal services.

Expedited Shipping:

For a faster delivery option, expedited shipping is available with an estimated delivery time of 4 to 7 working days. This option is ideal if you need the LCD panel urgently and prefer a quicker shipping method.

FX0305J1DSSWDG01 LCD Panel FAQ :

Q:Can you declared low value for my order when shipping?

A:Yes, We can do it for you if you need.

Q: What happen if the lcd panel FX0305J1DSSWDG01 I received can't work ?

A: All the goods will be tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.

Q: How to do if I can't find the screen that I require in your listings?

A: We should have it in stock , please contact us directly.if we dont't have it , we can try our best to find it for you .

Q: Why big order delivery time are long?

A: All the lcd panel are Strictly tested before shipment , to ensure that you receive good quality lcd panel and work well!
