4.3 inch 480*272 43WQW1H LCD screen Display for MP3 PMP
Product Details:
Place of Origin: | China |
Brand Name: | SII |
Model Number: | 43WQW1H |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Original packaging/conventional packaging box |
Delivery Time: | 7 Days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 100000 Unit/Units per Month |
Detail Information |
|||
Model Name: | 43WQW1H | Diagonal Size: | 4.3" |
---|---|---|---|
Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 480(RGB)×272, WQVGA 128PPI |
Pixel Format: | RGB Vertical Stripe | Active Area: | 95.04(W)×53.856(H) Mm |
Touchscreen: | Without | Designed For: | Portable Navigation、MP3 PMP |
Product Description
4.3 inch 480*272 43WQW1H LCD screen Display for MP3 PMP
43WQW1H LCD Panel Product details :
Brand | SII |
Model P/N | 43WQW1H |
Diagonal Size | 4.3" |
Panel Type | a-Si TFT-LCD, LCM |
Resolution | 480(RGB)×272, WQVGA 128PPI |
Pixel Format | RGB Vertical Stripe |
Active Area | 95.04(W)×53.856(H) mm |
Bezel Opening | 98.7(W)×57.5(H) mm |
Outline(mm) | 105.5 × 67.2× 3.5 (H×V×D) |
Treatment | Clear, Hard coating |
Luminance | 350 cd/m² (Typ.) |
Contrast Ratio | 400 : 1 (Typ.) (TM) |
Viewing Angle | 70/70/50/65 (Typ.)(CR≥10) |
Response | 15/35 (Typ.)(Tr/Td) ms |
Good View at | 6 o'clock |
Work Mode | TN, Normally White, Transmissive |
Color Depth | 16.2M 50%NTSC |
Backlight | 4S2PWLED |
Mass | 49.0g (Typ.) |
Used for | Portable Navigation,MP3 PMP |
Refresh Rate | - |
Touchscreen | Without |
Signal Type | Parallel RGB (1 ch, 8-bit) + SPI, 51 pinsFPC |
Max. Ratings | Storage Temp.: -30 ~ 70 °C Operating Temp.: -20 ~ 60 °C |
4.3 inch 480*272 43WQW1H LCD screen Display for MP3 PMP |
43WQW1H LCD Panel Shipping and Package :
43WQW1H LCD Panel FAQ :
Q: How long will I receive my goods 43WQW1H ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q:If I place order now,when will you ship the goods of 43WQW1H ?
A: The order will be shipped within 2-3 working days after received your payment.
Q:Do you accept sample orders of 43WQW1H ?
A:Of course!sample order is welcome !
Q: How long is the warranty ?
A: We offer 90days warranty .
