1024*768 8.4 inch COM84T8M02SSS LVDS 1000 : 1 LCD Monitor Parts

Brand Name:	Ortustech
Model Number:	COM84T8M02SSS
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

COM84T8M02SSS

Diagonal Size:

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

1024(RGB)×768, XGA 152PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

170.8(W)×128.1(H) Mm

Display Colors:

262K/16.7M 61% NTSC

Application:

Industrial

Supply Ability:

100000 Unit/Units per Month

Product Description

1024*768 8.4 inch COM84T8M02SSS LVDS 1000 : 1 LCD Monitor Parts

COM84T8M02SSS LCD Panel Product details :

Brand	Ortustech
Model P/N	COM84T8M02SSS
Diagonal Size	8.4"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1024(RGB)×768, XGA 152PPI
Pixel Format	RGB Vertical Stripe
Active Area	170.8(W)×128.1(H) mm
Bezel Opening	174.9(W)×132.2(H) mm
Outline(mm)	199.5(W)×149(H)×10.2(D)
Luminance	600 (Typ.)(cd/m²)
Viewing Angle	88/88/88/88 (Typ.)(CR≥10)
Good View at	Symmetry
Color Depth	262K/16.7M 61% NTSC
Mass	310g (Typ.)
Refresh Rate	60Hz
Treatment	-
Contrast Ratio	1000 : 1 (Typ.) (TM)
Work Mode	FFS, Normally Black, Transmissive
Response	40 (Max.)(Tr+Td) ms
Backlight	WLED , 100K hours
Used for	Industrial
Touchscreen	Without
Signal Type	LVDS (1 ch, 6/8-bit), 20 pins Connector
Voltage Supply	3.0V (Typ.)
Max. Ratings	Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C
