New 5.0 inch COM50T5124XTC 320*240 LCD Screen Display

Brand Name:	Ortustech
Model Number:	COM50T5124XTC
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

COM50T5124XTC

Diagonal Size:

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

320(RGB)×240, QVGA 80PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

100.8(W)×75.6(H) Mm

Touchscreen:

4-wire Resistive Touch

Application:

Industrial

Supply Ability:

100000 Unit/Units per Month

Product Description

New 5.0 inch COM50T5124XTC 320*240 LCD Screen Display

COM50T5124XTC LCD Panel Product details :

Brand	Ortustech
Model P/N	COM50T5124XTC
Diagonal Size	5.0"
Panel Type	a-Si TFT-LCD, LCM
Resolution	320(RGB)×240, QVGA 80PPI
Pixel Format	RGB Vertical Stripe
Active Area	100.8(W)×75.6(H) mm
Bezel Opening	-
Outline(mm)	108.3 × 87.55× 4.65 (H×V×D)
Treatment	Hard coating (3H)
Luminance	480 cd/m² (Typ.)
Contrast Ratio	400 : 1 (Typ.) (TM)
Viewing Angle	80/80/80/80 (Min.)(CR≥10)
Response	40/60 (Max.)(Tr/Td) ms
Good View at	-
Work Mode	TN, Normally White, Transmissive
Color Depth	262K/16.7M
Backlight	6S2PWLED, 50K hours, No Driver
Mass	80.0g (Typ.)
Used for	Industrial
Refresh Rate	60Hz
Touchscreen	4-wire Resistive Touch
Signal Type	Parallel RGB (1 ch, 6/8-bit), 67 pins FPC
Voltage Supply	3.0V (Typ.)
Max. Ratings	Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
