COM50T5M80GTC 5.0 inch 320*240 LCD Touch Monitor screen

Brand Name:	Ortustech
Model Number:	COM50T5M80GTC
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

COM50T5M80GTC

Diagonal Size:

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

320(RGB)×240, QVGA 80PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

100.8(W)×75.6(H) Mm

Used For:

Industrial

Refresh Rate:

Supply Ability:

100000 Unit/Units per Month

Product Description

COM50T5M80GTC 5.0 inch 320*240 LCD Touch Monitor screen

COM50T5M80GTC LCD Panel Product details :

Brand	Ortustech
Model P/N	COM50T5M80GTC
Diagonal Size	5.0"
Panel Type	a-Si TFT-LCD, LCM
Resolution	320(RGB)×240, QVGA 80PPI
Pixel Format	RGB Vertical Stripe
Active Area	100.8(W)×75.6(H) mm
Bezel Opening	-
Outline Dim.	108.3(W)×87.55(H)×4.65(D) mm
Treatment	Hard coating (3H)
Luminance	400 cd/m² (Typ.)
Contrast Ratio	200:1 (Typ.) (TM)
View Direction	6 o'clock
Response Time	40/60 (Max.)(Tr/Td)
Viewing Angle	35/35/20/50 (Typ.)(CR≥10)
Operating Mode	TN, Normally White, Transmissive
Support Color	262K/16.7M
Light Source	WLED [6S2P], 50K hours, W/O Driver
Weight	80.0g (Typ.)
Designed For	Industrial
Frame Rate	60Hz
Touch Panel	4-wire Resistive Touch
Interface Type	Parallel RGB (1 ch, 6/8-bit), 67 pinsFPC
Power Supply	3.0V (Typ.)
Environment	Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
COM50T5M80GTC 5.0 inch 320*240 LCD Touch Monitor screen

COM50T5M80GTC LCD Panel Note :

Model Verification:

Please ensure that the model number you need is exactly the same as the model number you have ordered. We will ship the LCD panel based strictly on the model specified in your order. Ensuring the correct model number is crucial to avoid any compatibility issues.

Comprehensive Testing:

We conduct 100% testing on each LCD panel to ensure it meets our stringent quality standards. This thorough testing process guarantees that you receive a fully functional and reliable product. Our commitment to quality ensures that each panel is meticulously checked before it is shipped to you.

COM50T5M80GTC LCD Panel Shipping and Package :

COM50T5M80GTC 5.0 inch 320*240 LCD Touch Monitor screen 0

COM50T5M80GTC LCD Panel Shipping Guidelines:

Address Confirmation:

It is crucial to verify that the shipping address provided in your order is accurate. We will ship the LCD panel to the address listed in the order. If you need the panel to be shipped to a different address, please email us the new address immediately after making the payment to avoid any shipping errors.

Shipment Timeline:

Your order will be processed and shipped within three business days after we have received your payment. Please note that business days do not include weekends or public holidays, so take this into account when estimating your delivery date.

COM50T5M80GTC LCD Panel ESTIMATED DELIVERY TIME :

Standard Shipping:

The estimated delivery time for standard shipping is between 10 to 35 working days. This timeframe may vary depending on the destination and other factors such as customs processing and local postal services.

Expedited Shipping:

For a faster delivery option, expedited shipping is available with an estimated delivery time of 4 to 7 working days. This option is ideal if you need the LCD panel urgently and prefer a quicker shipping method.

COM50T5M80GTC LCD Panel FAQ :

Q: How to make payment of COM50T5M80GTC ?

A: We accept T/T , Paypal , western union .

Q: Do you accept sample orders of COM50T5M80GTC ?

A: Of course!sample order is welcome !

Q: Can I pay my order of COM50T5M80GTC via credit card ?

A: Yes!you can use your credit card through your Paypal account.

Q: If I place order now,when will you ship the goods of COM50T5M80GTC ?

A: The order will be shipped within 2-3 working days after received your payment.
