small 5.0 inch COM50T5M78GLC 320*240 500 cd/m2 LCD Monitor Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | Ortustech |
| Model Number: | COM50T5M78GLC |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | COM50T5M78GLC | Diagonal Size: | 5.0" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 320(RGB)×240, QVGA 80PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 100.8(W)×75.6(H) Mm |
| Used For: | Industrial | Refresh Rate: | 60Hz |
Product Description
small 5.0 inch COM50T5M78GLC 320*240 500 cd/m2 LCD Monitor Panel
COM50T5M78GLC LCD Panel Product details :
| Brand | Ortustech |
| Model P/N | COM50T5M78GLC |
| Diagonal Size | 5.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 320(RGB)×240, QVGA 80PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 100.8(W)×75.6(H) mm |
| Bezel Opening | 104.10(W)×78.90(H) mm |
| Outline Size | 108.3(W)×87.55(H)×3.2(D) mm |
| Surface | Hard coating (3H) |
| Brightness | 500 cd/m² (Typ.) |
| Contrast Ratio | 200:1 (Typ.) (TM) |
| Viewing Angle | 35/35/20/50 (Min.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 6 o'clock |
| Response Time | 40/60 (Max.)(Tr/Td) |
| Display Colors | 262K/16.7M |
| Lamp Type | 6S2PWLED, 50K hours, Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 60.5g (Typ.) |
| Application | Industrial |
| Signal Interface | Parallel RGB (1 ch, 6/8-bit), 67 pinsFPC |
| Input Voltage | 3.0V (Typ.) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| small 5.0 inch COM50T5M78GLC 320*240 500 cd/m2 LCD Monitor Panel | |
