COM50H5M67XLX 5.0 inch 480*272 45 pins LCD Display Monitor

Brand Name:	Ortustech
Model Number:	COM50H5M67XLX
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

COM50H5M67XLX

Diagonal Size:

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

480×272(RGB), WQVGA 109PPI

Pixel Format:

RGB Horizontal Stripe

Active Area:

110.88(W)×62.832(H) Mm

Used For:

Industrial

Refresh Rate:

Supply Ability:

100000 Unit/Units per Month

Product Description

COM50H5M67XLX 5.0 inch 480*272 45 pins LCD Display Monitor

COM50H5M67XLX LCD Panel Product details :

Brand	Ortustech
Model P/N	COM50H5M67XLX
Diagonal Size	5.0"
Panel Type	a-Si TFT-LCD, LCM
Resolution	480×272(RGB), WQVGA 109PPI
Pixel Format	RGB Horizontal Stripe
Active Area	110.88(W)×62.832(H) mm
Bezel Opening	116.86(W)×65.68(H) mm
Outline(mm)	121.28(W)×75.23(H)×2.98(D)
Luminance	800 (Typ.)(cd/m²)
Viewing Angle	80/80/80/80 (Min.)(CR≥10)
Good View at	6 o'clock
Color Depth	16.7M
Mass	52.0g
Refresh Rate	60Hz
Treatment	Hard coating (3H)
Contrast Ratio	400 : 1 (Typ.) (TM) 5.5:1 (Typ.) (RF)
Work Mode	TN, Normally White, Transflective
Response	40/60 (Max.)(Tr/Td) ms
Backlight	6S2P WLED, No Driver
Used for	Industrial
Touchscreen	Without
Signal Type	Parallel RGB (1 ch, 6/8-bit) + SPI, 45 pins FPC
Voltage Supply	1.8/3.3V (Typ.)(VDDIO/VCI)
Max. Ratings	Storage Temp.: -20 ~ 80 °C Operating Temp.: -10 ~ 70 °C
COM50H5M67XLX 5.0 inch 480*272 45 pins LCD Display Monitor

COM50H5M67XLX LCD Panel Note :

Model Verification:

Please ensure that the model number you need is exactly the same as the model number you have ordered. We will ship the LCD panel based strictly on the model specified in your order. Ensuring the correct model number is crucial to avoid any compatibility issues.

Comprehensive Testing:

We conduct 100% testing on each LCD panel to ensure it meets our stringent quality standards. This thorough testing process guarantees that you receive a fully functional and reliable product. Our commitment to quality ensures that each panel is meticulously checked before it is shipped to you.

COM50H5M67XLX LCD Panel Shipping and Package :

COM50H5M67XLX 5.0 inch 480*272 45 pins LCD Display Monitor 0

COM50H5M67XLX LCD Panel Shipping Guidelines:

Address Confirmation:

It is crucial to verify that the shipping address provided in your order is accurate. We will ship the LCD panel to the address listed in the order. If you need the panel to be shipped to a different address, please email us the new address immediately after making the payment to avoid any shipping errors.

Shipment Timeline:

Your order will be processed and shipped within three business days after we have received your payment. Please note that business days do not include weekends or public holidays, so take this into account when estimating your delivery date.

COM50H5M67XLX LCD Panel ESTIMATED DELIVERY TIME :

Standard Shipping:

The estimated delivery time for standard shipping is between 10 to 35 working days. This timeframe may vary depending on the destination and other factors such as customs processing and local postal services.

Expedited Shipping:

For a faster delivery option, expedited shipping is available with an estimated delivery time of 4 to 7 working days. This option is ideal if you need the LCD panel urgently and prefer a quicker shipping method.

COM50H5M67XLX LCD Panel FAQ :

Q:Can you declared low value for my order when shipping?

A:Yes, We can do it for you if you need.

Q: What happen if the lcd panel COM50H5M67XLX I received can't work ?

A: All the goods will be tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.

Q: How to do if I can't find the screen that I require in your listings?

A: We should have it in stock , please contact us directly.if we dont't have it , we can try our best to find it for you .

Q: Why big order delivery time are long?

A: All the lcd panel are Strictly tested before shipment , to ensure that you receive good quality lcd panel and work well!
