hot sell 4.3 inch 480*272 COM43H4N44ULC 45 pins LCD Display

All Category

Floor Standing Digital Signage

Stretched Bar LCD Display

chance

info@yongs-hk.com

86-18575563918

Contact Now

hot sell 4.3 inch 480*272 COM43H4N44ULC 45 pins LCD Display

Brand Name:	Ortustech
Model Number:	COM43H4N44ULC
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

COM43H4N44ULC

Diagonal Size:

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

480(RGB)×272, WQVGA 128PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

95.04(W)×53.856(H) Mm

Used For:

Industrial、Automotive Display

Refresh Rate:

Supply Ability:

100000 Unit/Units per Month

Product Description

hot sell 4.3 inch 480*272 COM43H4N44ULC 45 pins LCD Display

COM43H4N44ULC LCD Panel Product details :

Brand	Ortustech
Model P/N	COM43H4N44ULC
Diagonal Size	4.3"
Panel Type	a-Si TFT-LCD, LCM
Resolution	480×272(RGB), WQVGA 128PPI
Pixel Format	RGB Horizontal Stripe
Active Area	95.04(W)×53.856(H) mm
Bezel Opening	-
Outline(mm)	105.5 × 67.2× 5.4 (H×V×D)
Treatment	Hard coating (2H)
Luminance	1100 cd/m² (Typ.)
Contrast Ratio	600 : 1 (Typ.) (TM) 2:1 (Typ.) (RF)
Viewing Angle	80/80/80/80 (Min.)(CR≥10)
Response	50 (Typ.)(Tr+Td) ms
Good View at	Symmetry
Work Mode	VA, Normally Black, Transflective
Color Depth	16.7M 50%NTSC
Backlight	4S2PWLED, 50K hours, No Driver
Mass	62.0g (Typ.)
Used for	Industrial,Automotive Display
Refresh Rate	60Hz
Touchscreen	Without
Signal Type	Parallel RGB (1 ch, 8-bit), 45 pins FPC
Voltage Supply	3.3V (Typ.)
Max. Ratings	Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²)
hot sell 4.3 inch 480*272 COM43H4N44ULC 45 pins LCD Display

COM43H4N44ULC LCD Panel Note :

Model Verification:

Please ensure that the model number you need is exactly the same as the model number you have ordered. We will ship the LCD panel based strictly on the model specified in your order. Ensuring the correct model number is crucial to avoid any compatibility issues.

Comprehensive Testing:

We conduct 100% testing on each LCD panel to ensure it meets our stringent quality standards. This thorough testing process guarantees that you receive a fully functional and reliable product. Our commitment to quality ensures that each panel is meticulously checked before it is shipped to you.

COM43H4N44ULC LCD Panel Shipping and Package :

hot sell 4.3 inch 480*272 COM43H4N44ULC 45 pins LCD Display 0

COM43H4N44ULC LCD Panel Shipping Guidelines:

Address Confirmation:

It is crucial to verify that the shipping address provided in your order is accurate. We will ship the LCD panel to the address listed in the order. If you need the panel to be shipped to a different address, please email us the new address immediately after making the payment to avoid any shipping errors.

Shipment Timeline:

Your order will be processed and shipped within three business days after we have received your payment. Please note that business days do not include weekends or public holidays, so take this into account when estimating your delivery date.

COM43H4N44ULC LCD Panel ESTIMATED DELIVERY TIME :

Standard Shipping:

The estimated delivery time for standard shipping is between 10 to 35 working days. This timeframe may vary depending on the destination and other factors such as customs processing and local postal services.

Expedited Shipping:

For a faster delivery option, expedited shipping is available with an estimated delivery time of 4 to 7 working days. This option is ideal if you need the LCD panel urgently and prefer a quicker shipping method.

COM43H4N44ULC LCD Panel FAQ :

Q: How can I trace my order of COM43H4N44ULC ?

A: we will give you tracking number then you can trace your order from website.

Q: If I place order now,when will you ship the goods of COM43H4N44ULC ?

A: The order will be shipped within 2-3 working days after received your payment.

Q: Do you accept sample orders of COM43H4N44ULC ?

A: Of course!sample order is welcome !

Q: Can you give me a discount if I need a large quantity of COM43H4N44ULC ?

A: Of course!If you make a large order, we will give you a discount.
