ETMV570G2DHU 5.7 inch 640*480 40 pins lcd Display
Product Details:
| Place of Origin: | China |
| Brand Name: | EDT |
| Model Number: | ETMV570G2DHU |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union, D/P |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | ETMV570G2DHU | Diagonal Size: | 5.7" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 640(RGB)×480, VGA 141PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 115.2(W)×86.4(H) Mm |
| Used For: | Industrial | Touch Panel: | PCAP, I²C/SPI |
Product Description
ETMV570G2DHU 5.7 inch 640*480 40 pins lcd Display
ETMV570G2DHU LCD Panel Product details :
| Brand | EDT |
| Model P/N | ETMV570G2DHU |
| Diagonal Size | 5.7" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 640(RGB)×480, VGA 141PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 115.2(W)×86.4(H) mm |
| Bezel Opening | 118.8(W)×90.6(H) mm |
| Outline Dim. | 147.6(H)×100(V)×11.7(D)mm |
| Treatment | - |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 350:1 (Typ.) (TM) |
| View Direction | 12 o'clock |
| Response Time | 15/35 (Typ.)(Tr/Td) |
| Viewing Angle | 65/65/55/52 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 262K 51%NTSC |
| Light Source | WLED [9S2P], 40K hours, W/O Driver |
| Weight | - |
| Designed For | Industrial |
| Frame Rate | 60Hz |
| Touch Panel | PCAP, I²C/SPI |
| Interface Type | Parallel RGB (1 ch, 6-bit), 40 pinsConnector |
| Power Supply | 3.3/3.3V (Typ.)(VDD/VCC) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| ETMV570G2DHU 5.7 inch 640*480 40 pins lcd Display | |
ETMV570G2DHU LCD Panel Shipping and Package :
ETMV570G2DHU LCD Panel FAQ :
Q: How to do if I can't find the screen that I require in your listings?
A: We should have it in stock , please contact us directly.if we dont't have it , we can try our best to find it for you .
Q: What does "We may ship a 100% compatible part number for your screen" mean?
A: Because some original screens are not available in the market , So we send the compatible item to you .Don't worry , it is 100% compatible for your screen.
Q: How long is the warranty of ETMV570G2DHU ?
A: NEW Product warranty is 90 days.
Q: How to order lcd panel ETMV570G2DHU ?
A: Tell us the quantity you need ,Then we will make a PI for you to confirm the order details ,When we confirmed everything, you can arrange the payment ,After we received the payment, we will ship goods to you within 1-2day.
