Name: ORIGINAL 12.1 inch ETML121000DHA 1280*800 LVDS lcd screen
Brand: Shenzhen Yongsheng Innovation Technology Co., Ltd
SKU: ETML121000DHA
Availability: InStock

Brand Name:	EDT
Model Number:	ETML121000DHA
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union, D/P

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

ETML121000DHA

Diagonal Size:

12.1"

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

1280(RGB)×800, WXGA 124PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

261.12(W)×163.2(H) Mm

Used For:

Industrial

Touch Panel:

PCAP, USB

Supply Ability:

100000 Unit/Units per Month

Product Description

ORIGINAL 12.1 inch ETML121000DHA 1280*800 LVDS lcd screen

ETML121000DHA LCD Panel Product details :

Brand	EDT
Model P/N	ETML121000DHA
Diagonal Size	12.1"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1280(RGB)×800, WXGA 124PPI
Pixel Format	RGB Vertical Stripe
Active Area	261.12(W)×163.2(H) mm
Bezel Opening	264.12(W)×166.2(H) mm
Outline Dim.	278(H)×184(V)×12.2(D) mm
Treatment	Hard coating (7H)
Luminance	340 cd/m² (Typ.)
Contrast Ratio	1000:1 (Typ.) (TM)
View Direction	Symmetry
Response Time	5/10 (Typ.)(Tr/Td)
Viewing Angle	88/88/88/88 (Typ.)(CR≥10)
Operating Mode	Normally Black, Transmissive
Support Color	262K/16.7M 45%NTSC
Light Source	WLED, 50K hours, With LED Driver
Weight	-
Designed For	Industrial
Frame Rate	60Hz
Touch Panel	PCAP, USB
Interface Type	LVDS (1 ch, 6/8-bit), 30 pinsConnector
Power Supply	3.3V (Typ.)
Environment	Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
ORIGINAL 12.1 inch ETML121000DHA 1280*800 LVDS lcd screen

ETML121000DHA LCD Display Features :

High Quality:

Highest quality touch LCD screen replacement parts.

Repair Utility:

Suitable for repairing faulty screens, touch screen problems, dead pixels, cracked touchscreens, and other related issues.

Thorough Testing:

Each assembly is tested before shipping to ensure 100% functionality.

Quality control includes checks for dark spots, color points, and dead pixels, ensuring no defects.

ETML121000DHA LCD Panel Shipping and Package :

ORIGINAL 12.1 inch ETML121000DHA 1280*800 LVDS lcd screen 0

ETML121000DHA LCD Display Shipping Policy :

Shipping Method:

If the buyer selects a specific courier (e.g., FedEx), we may ship the product using an equivalent service level from other logistics companies such as DHL, UPS, TNT, or others.

Specified Logistics:

If you require a specific logistics company, please inform us in advance.

ETML121000DHA LCD Display Return Policy :

Product Status:

The product's condition (new or old) will be indicated in the product title.

Return and Exchange Conditions:

If the product encounters quality problems within 30 days of receipt, we offer free returns and exchanges.

Return Procedure:

When returning the product, please provide a detailed explanation of the issues encountered.

Include actual photos showing the problems with the product.

ETML121000DHA LCD Panel FAQ :

Q:If I place order now,when will you ship the goods of ETML121000DHA ?

A: The order will be shipped within 2-3 working days after received your payment.

Q:Do you accept sample orders of ETML121000DHA ?

A:Of course!sample order is welcome !

Q: How long is the warranty ?

A: We offer 90days warranty .

Q: How long will I receive my goods ETML121000DHA ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
