ETML101003DKA 10.1 inch 1280*800 40 pins lcd screen Industrial
Product Details:
| Place of Origin: | China |
| Brand Name: | EDT |
| Model Number: | ETML101003DKA |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union, D/P |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | ETML101003DKA | Diagonal Size: | 10.1" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 1280(RGB)×800, WXGA 149PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 216.96(W)×135.6(H) Mm |
| Used For: | Industrial、Outdoor High Brightness | Touch Panel: | PCAP, I²C |
Product Description
ETML101003DKA 10.1 inch 1280*800 40 pins lcd screen Industrial
ETML101003DKA LCD Panel Product details :
| Brand | EDT |
| Model P/N | ETML101003DKA |
| Diagonal Size | 10.1" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1280(RGB)×800, WXGA 149PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 216.96(W)×135.6(H) mm |
| Bezel Opening | 218.56(W)×137.2(H) mm |
| Outline Dim. | 229.8(H)×150(V)×12.8(D) mm |
| Treatment | Hard coating (7H) |
| Luminance | 850 cd/m² (Typ.) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Operating Mode | Normally Black, Transmissive |
| Support Color | 16.7M 50%NTSC |
| Light Source | WLED, 70K hours, With LED Driver |
| Weight | - |
| Designed For | Industrial,Outdoor High Brightness |
| Frame Rate | 60Hz |
| Touch Panel | PCAP, I²C |
| Interface Type | LVDS (1 ch, 8-bit), 40 pinsConnector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| ETML101003DKA 10.1 inch 1280*800 40 pins lcd screen Industrial | |
ETML101003DKA LCD Display Features :
High Quality:
Highest quality touch LCD screen replacement parts.
Repair Utility:
Suitable for repairing faulty screens, touch screen problems, dead pixels, cracked touchscreens, and other related issues.
Thorough Testing:
Each assembly is tested before shipping to ensure 100% functionality.
Quality control includes checks for dark spots, color points, and dead pixels, ensuring no defects.
ETML101003DKA LCD Panel Shipping and Package :
ETML101003DKA LCD Display Shipping Policy :
Shipping Method:
If the buyer selects a specific courier (e.g., FedEx), we may ship the product using an equivalent service level from other logistics companies such as DHL, UPS, TNT, or others.
Specified Logistics:
If you require a specific logistics company, please inform us in advance.
ETML101003DKA LCD Display Return Policy :
Product Status:
The product's condition (new or old) will be indicated in the product title.
Return and Exchange Conditions:
If the product encounters quality problems within 30 days of receipt, we offer free returns and exchanges.
Return Procedure:
When returning the product, please provide a detailed explanation of the issues encountered.
Include actual photos showing the problems with the product.
ETML101003DKA LCD Panel FAQ :
Q:Do you accept sample orders of ETML101003DKA ?
A:Of course!sample order is welcome !
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: How long will I receive my goods ETML101003DKA ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q:If I place order now,when will you ship the goods of ETML101003DKA ?
A: The order will be shipped within 2-3 working days after received your payment.
