Name: ETM035080BDH6 320*240 3.5 inch 60Hz LCD screen Panel for PDA
Brand: Shenzhen Yongsheng Innovation Technology Co., Ltd
SKU: ETM035080BDH6
Availability: InStock

Brand Name:	EDT
Model Number:	ETM035080BDH6
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union, D/P

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

ETM035080BDH6

Diagonal Size:

3.5"

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

320(RGB)×240, QVGA 115PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

70.08(W)×52.56(H) Mm

Used For:

Industrial、Handheld & PDA

Touch Panel:

PCAP, I²C

Supply Ability:

100000 Unit/Units per Month

Product Description

ETM035080BDH6 320*240 3.5 inch 60Hz LCD screen Panel for PDA

ETM035080BDH6 LCD Panel Product details :

Brand	EDT
Model P/N	ETM035080BDH6
Diagonal Size	3.5"
Panel Type	a-Si TFT-LCD, LCM
Resolution	320(RGB)×240, QVGA 115PPI
Pixel Format	RGB Vertical Stripe
Active Area	70.08(W)×52.56(H) mm
Bezel Opening	-
Outline Size	76.8(W)×63.8(H)×9.2(D) mm
Surface	Hard coating (7H)
Brightness	340 cd/m² (Typ.)
Contrast Ratio	450:1 (Typ.) (TM)
Viewing Angle	75/75/55/75 (Typ.)(CR≥10)
Display Mode	TN, Normally White, Transmissive
Best View on	-
Response Time	15/35 (Typ.)(Tr/Td)
Display Colors	262K 54%NTSC
Lamp Type	6S1PWLED, 40K hours, With LED Driver
Frequency	60Hz
Touch Screen	PCAP, I²C
Panel Weight	-
Application	Industrial,Handheld & PDA
Signal Interface	TTL (1 ch, 8-bit) + SPI, 40 pins Connector
Input Voltage	3.3/3.3V (Typ.)(VCC/VDD)
Environment	Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 80 °C
ETM035080BDH6 320*240 3.5 inch 60Hz LCD screen Panel for PDA

ETM035080BDH6 LCD Display Features :

High Quality:

Highest quality touch LCD screen replacement parts.

Repair Utility:

Suitable for repairing faulty screens, touch screen problems, dead pixels, cracked touchscreens, and other related issues.

Thorough Testing:

Each assembly is tested before shipping to ensure 100% functionality.

Quality control includes checks for dark spots, color points, and dead pixels, ensuring no defects.

ETM035080BDH6 LCD Panel Shipping and Package :

ETM035080BDH6 320*240 3.5 inch 60Hz LCD screen Panel for PDA 0

ETM035080BDH6 LCD Display Shipping Policy :

Shipping Method:

If the buyer selects a specific courier (e.g., FedEx), we may ship the product using an equivalent service level from other logistics companies such as DHL, UPS, TNT, or others.

Specified Logistics:

If you require a specific logistics company, please inform us in advance.

ETM035080BDH6 LCD Display Return Policy :

Product Status:

The product's condition (new or old) will be indicated in the product title.

Return and Exchange Conditions:

If the product encounters quality problems within 30 days of receipt, we offer free returns and exchanges.

Return Procedure:

When returning the product, please provide a detailed explanation of the issues encountered.

Include actual photos showing the problems with the product.

ETM035080BDH6 LCD Panel FAQ :

Q: How long will I receive my goods of lcd ETM035080BDH6 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.

Q: When will my order ETM035080BDH6 ship?

A: The order are shipped within 1-2 working days after received the payment.

Q: Do you accept the sample order?

A: Yes , sample order is welcome.

Q: What does "We may ship a 100% compatible part number for your screen" mean?

A: Because some original screens are not available in the market , So we send the compatible item to you .Don't worry , it is 100% compatible for your screen.
