Name: ETM0700G0EDH6 800*480 7.0 inch 262K 40 pins LCD screen
Brand: Shenzhen Yongsheng Innovation Technology Co., Ltd
SKU: ETM0700G0EDH6
Availability: InStock

Brand Name:	EDT
Model Number:	ETM0700G0EDH6
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union, D/P

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

ETM0700G0EDH6

Diagonal Size:

7.0"

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

800(RGB)×480, WVGA 133PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

152.4(W)×91.44(H) Mm

Used For:

Industrial

Touch Panel:

PCAP, I²C

Supply Ability:

100000 Unit/Units per Month

Product Description

ETM0700G0EDH6 800*480 7.0 inch 262K 40 pins LCD screen

ETM0700G0EDH6 LCD Panel Product details :

Brand	EDT
Model P/N	ETM0700G0EDH6
Diagonal Size	7.0"
Panel Type	a-Si TFT-LCD, LCM
Resolution	800(RGB)×480, WVGA 133PPI
Pixel Format	RGB Vertical Stripe
Active Area	152.4(W)×91.44(H) mm
Bezel Opening	-
Outline Dim.	166(H)×105.44(V)×11.6(D) mm
Treatment	Antiglare
Luminance	350 cd/m² (Typ.)
Contrast Ratio	900:1 (Typ.) (TM)
View Direction	-
Response Time	5/15 (Typ.)(Tr/Td)
Viewing Angle	75/75/70/75 (Typ.)(CR≥10)
Operating Mode	TN, Normally White, Transmissive
Support Color	262K 74%NTSC
Light Source	WLED [3S8P], 40K hours, W/O Driver
Weight	-
Designed For	Industrial
Frame Rate	-
Touch Panel	PCAP, I²C
Interface Type	Parallel RGB (1 ch, 6-bit), 40 pinsConnector
Power Supply	3.3/3.3V (Typ.)(VDD/VCC)
Environment	Operating Temperature: -20 ~ 70 °C; Storage Temperature: -30 ~ 80 °C
ETM0700G0EDH6 800*480 7.0 inch 262K 40 pins LCD screen

ETM0700G0EDH6 LCD Display Features :

High Quality:

Highest quality touch LCD screen replacement parts.

Repair Utility:

Suitable for repairing faulty screens, touch screen problems, dead pixels, cracked touchscreens, and other related issues.

Thorough Testing:

Each assembly is tested before shipping to ensure 100% functionality.

Quality control includes checks for dark spots, color points, and dead pixels, ensuring no defects.

ETM0700G0EDH6 LCD Panel Shipping and Package :

ETM0700G0EDH6 800*480 7.0 inch 262K 40 pins LCD screen 0

ETM0700G0EDH6 LCD Display Shipping Policy :

Shipping Method:

If the buyer selects a specific courier (e.g., FedEx), we may ship the product using an equivalent service level from other logistics companies such as DHL, UPS, TNT, or others.

Specified Logistics:

If you require a specific logistics company, please inform us in advance.

ETM0700G0EDH6 LCD Display Return Policy :

Product Status:

The product's condition (new or old) will be indicated in the product title.

Return and Exchange Conditions:

If the product encounters quality problems within 30 days of receipt, we offer free returns and exchanges.

Return Procedure:

When returning the product, please provide a detailed explanation of the issues encountered.

Include actual photos showing the problems with the product.

ETM0700G0EDH6 LCD Panel FAQ :

Q: Do you accept the sample order?

A: Yes , sample order is welcome.

Q: What does "We may ship a 100% compatible part number for your screen" mean?

A: Because some original screens are not available in the market , So we send the compatible item to you .Don't worry , it is 100% compatible for your screen.

Q: How long will I receive my goods of lcd ETM0700G0EDH6 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.

Q: When will my order ETM0700G0EDH6 ship?

A: The order are shipped within 1-2 working days after received the payment.
