NEW 640*480 ET057005DHU 5.7 inch LCD Touch Panel screen
Product Details:
| Place of Origin: | China |
| Brand Name: | EDT |
| Model Number: | ET057005DHU |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union, D/P |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | ET057005DHU | Diagonal Size: | 5.7" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 640(RGB)×480, VGA 141PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 115.2(W)×86.4(H) Mm |
| Used For: | Industrial | Backlight: | 9S2PWLED, 40K Hours, No Driver |
Product Description
NEW 640*480 ET057005DHU 5.7 inch LCD Touch Panel screen
ET057005DHU LCD Panel Product details :
| Brand | EDT |
| Model P/N | ET057005DHU |
| Diagonal Size | 5.7" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 640(RGB)×480, VGA 141PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 115.2(W)×86.4(H) mm |
| Bezel Opening | 117.2(W)×88.4(H) mm |
| Outline (mm) | 147.6×100×7.8 (H×V×D) |
| Treatment | - |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 350 : 1 (Typ.) (TM) |
| Viewing Angle | 65/65/55/52 (Typ.)(CR≥10) |
| Response | 15/35 (Typ.)(Tr/Td) ms |
| Good View at | 12 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 16.7M 51%NTSC |
| Backlight | 9S2PWLED, 40K hours, No Driver |
| Mass | - |
| Used for | Industrial |
| Refresh Rate | 60Hz |
| Touchscreen | 4-wire Resistive Touch |
| Signal Type | Parallel RGB (1 ch, 8-bit) + SPI, FPC54 pins |
| Voltage Supply | 3.3/11.6/16.0/-7.0V (Typ.)(VCC/VDDA/VGH/VGL) |
| Max. Ratings | Storage Temp.: -20 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
| NEW 640*480 ET057005DHU 5.7 inch LCD Touch Panel screen | |
ET057005DHU LCD Display Features :
High Quality:
Highest quality touch LCD screen replacement parts.
Repair Utility:
Suitable for repairing faulty screens, touch screen problems, dead pixels, cracked touchscreens, and other related issues.
Thorough Testing:
Each assembly is tested before shipping to ensure 100% functionality.
Quality control includes checks for dark spots, color points, and dead pixels, ensuring no defects.
ET057005DHU LCD Panel Shipping and Package :
ET057005DHU LCD Display Shipping Policy :
Shipping Method:
If the buyer selects a specific courier (e.g., FedEx), we may ship the product using an equivalent service level from other logistics companies such as DHL, UPS, TNT, or others.
Specified Logistics:
If you require a specific logistics company, please inform us in advance.
ET057005DHU LCD Display Return Policy :
Product Status:
The product's condition (new or old) will be indicated in the product title.
Return and Exchange Conditions:
If the product encounters quality problems within 30 days of receipt, we offer free returns and exchanges.
Return Procedure:
When returning the product, please provide a detailed explanation of the issues encountered.
Include actual photos showing the problems with the product.
ET057005DHU LCD Panel FAQ :
Q: If I place order now,when will you ship the goods of ET057005DHU ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Can I pay my order of ET057005DHU via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can You declare my order of ET057005DHU to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How long will I receive my goods ET057005DHU ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
