Name: ET057002DH6 5.7 inch 320*240 380 cd/m2 262K LCD screen Parts
Brand: Shenzhen Yongsheng Innovation Technology Co., Ltd
SKU: ET057002DH6
Availability: InStock

Brand Name:	EDT
Model Number:	ET057002DH6
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union, D/P

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

ET057002DH6

Diagonal Size:

5.7"

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

320(RGB)×240, QVGA 70PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

115.2(W)×86.4(H) Mm

Used For:

Industrial

Touch Panel:

4-wire Resistive Touch

Supply Ability:

100000 Unit/Units per Month

Product Description

ET057002DH6 5.7 inch 320*240 380 cd/m2 262K LCD screen Parts

ET057002DH6 LCD Panel Product details :

Brand	EDT
Model P/N	ET057002DH6
Diagonal Size	5.7"
Panel Type	a-Si TFT-LCD, LCM
Resolution	320(RGB)×240, QVGA 70PPI
Pixel Format	RGB Vertical Stripe
Active Area	115.2(W)×86.4(H) mm
Bezel Opening	-
Outline Size	124.7(W)×100(H)×8(D) mm
Surface	-
Brightness	380 cd/m² (Typ.)
Contrast Ratio	300:1 (Typ.) (TM)
Viewing Angle	67/67/62/67 (Typ.)(CR≥10)
Display Mode	TN, Normally White, Transmissive
Best View on	6 o'clock
Response Time	15/35 (Typ.)(Tr/Td)
Display Colors	262K/16.7M 54%NTSC
Lamp Type	9S2PWLED, 40K hours, Without Driver
Frequency	60Hz
Touch Screen	4-wire Resistive Touch
Panel Weight	-
Application	Industrial
Signal Interface	Parallel RGB (1 ch, 6/8-bit), 50 pinsFPC
Input Voltage	3.3/5.0/15/-10V (Typ.)(VCC/VDD/VHG/VGL)
Environment	Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -20 ~ 70 °C
ET057002DH6 5.7 inch 320*240 380 cd/m2 262K LCD screen Parts

ET057002DH6 LCD Display Features :

High Quality:

Highest quality touch LCD screen replacement parts.

Repair Utility:

Suitable for repairing faulty screens, touch screen problems, dead pixels, cracked touchscreens, and other related issues.

Thorough Testing:

Each assembly is tested before shipping to ensure 100% functionality.

Quality control includes checks for dark spots, color points, and dead pixels, ensuring no defects.

ET057002DH6 LCD Panel Shipping and Package :

ET057002DH6 5.7 inch 320*240 380 cd/m2 262K LCD screen Parts 0

ET057002DH6 LCD Display Shipping Policy :

Shipping Method:

If the buyer selects a specific courier (e.g., FedEx), we may ship the product using an equivalent service level from other logistics companies such as DHL, UPS, TNT, or others.

Specified Logistics:

If you require a specific logistics company, please inform us in advance.

ET057002DH6 LCD Display Return Policy :

Product Status:

The product's condition (new or old) will be indicated in the product title.

Return and Exchange Conditions:

If the product encounters quality problems within 30 days of receipt, we offer free returns and exchanges.

Return Procedure:

When returning the product, please provide a detailed explanation of the issues encountered.

Include actual photos showing the problems with the product.

ET057002DH6 LCD Panel FAQ :

Q: Do you accept the sample order?

A: Yes , sample order is welcome.

Q: How to order if I don't know the lcd panel number ?

A: You can offer 2-3 photos (back-side and front-side) for your lcd panel ,So that we can check the panel to you.

Q: When would you ship,IF I order ET057002DH6 now?

A: The order are shipped within 1-2 working days after received the payment.

Q: Can you declared low value for my order when shipping?

A: Yes, We can do it for you if you need.
