NEW 4.3 inch 480*272 ET043002DH6 60Hz LCD Panel Display
Product Details:
| Place of Origin: | China |
| Brand Name: | EDT |
| Model Number: | ET043002DH6 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union, D/P |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | ET043002DH6 | Diagonal Size: | 4.3" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 480(RGB)×272, WQVGA 128PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 95.04(W)×53.856(H) Mm |
| Used For: | Portable Navigation、MP3 PMP | Touch Panel: | 4-wire Resistive Touch |
Product Description
NEW 4.3 inch 480*272 ET043002DH6 60Hz LCD Panel Display
ET043002DH6 LCD Panel Product details :
| Brand | EDT |
| Model P/N | ET043002DH6 |
| Diagonal Size | 4.3" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 480(RGB)×272, WQVGA 128PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 95.04(W)×53.856(H) mm |
| Bezel Opening | - |
| Outline(mm) | 105.5(W)×67.2(H)×4.3(D) |
| Luminance | 350 (Typ.)(cd/m²) |
| Viewing Angle | 75/75/45/75 (Typ.)(CR≥10) |
| Good View at | 6 o'clock |
| Color Depth | 16.7M 55% NTSC |
| Mass | - |
| Refresh Rate | 60Hz |
| Treatment | - |
| Contrast Ratio | 400 : 1 (Typ.) (TM) |
| Work Mode | TN, Normally White, Transmissive |
| Response | 15/35 (Typ.)(Tr/Td) ms |
| Backlight | 10S1P WLED , 40K hours , No Driver |
| Used for | Portable Navigation,MP3 PMP |
| Touchscreen | 4-wire Resistive Touch |
| Signal Type | Parallel RGB (1 ch, 8-bit), 45 pins FPC |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| NEW 4.3 inch 480*272 ET043002DH6 60Hz LCD Panel Display | |
ET043002DH6 LCD Display Features :
High Quality:
Highest quality touch LCD screen replacement parts.
Repair Utility:
Suitable for repairing faulty screens, touch screen problems, dead pixels, cracked touchscreens, and other related issues.
Thorough Testing:
Each assembly is tested before shipping to ensure 100% functionality.
Quality control includes checks for dark spots, color points, and dead pixels, ensuring no defects.
ET043002DH6 LCD Panel Shipping and Package :
ET043002DH6 LCD Display Shipping Policy :
Shipping Method:
If the buyer selects a specific courier (e.g., FedEx), we may ship the product using an equivalent service level from other logistics companies such as DHL, UPS, TNT, or others.
Specified Logistics:
If you require a specific logistics company, please inform us in advance.
ET043002DH6 LCD Display Return Policy :
Product Status:
The product's condition (new or old) will be indicated in the product title.
Return and Exchange Conditions:
If the product encounters quality problems within 30 days of receipt, we offer free returns and exchanges.
Return Procedure:
When returning the product, please provide a detailed explanation of the issues encountered.
Include actual photos showing the problems with the product.
ET043002DH6 LCD Panel FAQ :
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: Can I pay my order of ET043002DH6 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can you give me a discount if I need a large quantity of ET043002DH6 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can You declare my order of ET043002DH6 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
