Name: High Quality 240*320 ET032001DH9 3.2 inch LCD Panel Screen
Brand: Shenzhen Yongsheng Innovation Technology Co., Ltd
SKU: ET032001DH9
Availability: InStock

Brand Name:	EDT
Model Number:	ET032001DH9
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union, D/P

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

ET032001DH9

Diagonal Size:

3.2"

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

240(RGB)×320, QVGA 125PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

48.6(W)×64.8(H) Mm

Used For:

Mobile Phone

Touchscreen:

4-wire Resistive Touch

Supply Ability:

100000 Unit/Units per Month

Product Description

High Quality 240*320 ET032001DH9 3.2 inch LCD Panel Screen

ET032001DH9 LCD Panel Product details :

Brand	EDT
Model P/N	ET032001DH9
Diagonal Size	3.2"
Panel Type	a-Si TFT-LCD, LCM
Resolution	240(RGB)×320, QVGA 125PPI
Pixel Format	RGB Vertical Stripe
Active Area	48.6(W)×64.8(H) mm
Bezel Opening	-
Outline Dim.	55.14(W)×79.3(H)×7.2(D) mm
Treatment	-
Luminance	300 cd/m² (Typ.)
Contrast Ratio	500:1 (Typ.) (TM)
View Direction	9 o'clock
Response Time	25 (Typ.)(Tr+Td)
Viewing Angle	55/75/72/72 (Typ.)(CR≥10)
Operating Mode	TN, Normally White, Transmissive
Support Color	262K 65%NTSC
Light Source	WLED [6S1P], 40K hours, W/O Driver
Weight	-
Designed For	Mobile Phone
Frame Rate	-
Touch Panel	4-wire Resistive Touch
Interface Type	CPU/SPI, 41 pinsFPC
Power Supply	3.0/3.0V (Typ.)(VCC/VCI)
Environment	Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C
High Quality 240*320 ET032001DH9 3.2 inch LCD Panel Screen

ET032001DH9 LCD Display Features :

High Quality:

Highest quality touch LCD screen replacement parts.

Repair Utility:

Suitable for repairing faulty screens, touch screen problems, dead pixels, cracked touchscreens, and other related issues.

Thorough Testing:

Each assembly is tested before shipping to ensure 100% functionality.

Quality control includes checks for dark spots, color points, and dead pixels, ensuring no defects.

ET032001DH9 LCD Panel Shipping and Package :

High Quality 240*320 ET032001DH9 3.2 inch LCD Panel Screen 0

ET032001DH9 LCD Display Shipping Policy :

Shipping Method:

If the buyer selects a specific courier (e.g., FedEx), we may ship the product using an equivalent service level from other logistics companies such as DHL, UPS, TNT, or others.

Specified Logistics:

If you require a specific logistics company, please inform us in advance.

ET032001DH9 LCD Display Return Policy :

Product Status:

The product's condition (new or old) will be indicated in the product title.

Return and Exchange Conditions:

If the product encounters quality problems within 30 days of receipt, we offer free returns and exchanges.

Return Procedure:

When returning the product, please provide a detailed explanation of the issues encountered.

Include actual photos showing the problems with the product.

ET032001DH9 LCD Panel FAQ :

Q: Can you give me a discount if I need a large quantity of ET032001DH9 ?

A: Of course!If you make a large order, we will give you a discount.

Q: Can You declare my order of ET032001DH9 to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .

Q: How long is the warranty ?

A: We offer 90days warranty .

Q: Can I pay my order of ET032001DH9 via credit card ?

A: Yes!you can use your credit card through your Paypal account.
