3.5 inch ET0350A6DM6 320*240 LCD Screen LCD for Handheld
Product Details:
| Place of Origin: | China |
| Brand Name: | EDT |
| Model Number: | ET0350A6DM6 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | ET0350A6DM6 | Diagonal Size: | 3.5" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 320(RGB)×240, QVGA 115PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 70.08(W)×52.56(H) Mm |
| Used For: | Handheld & PDA | Touchscreen: | Without |
Product Description
3.5 inch ET0350A6DM6 320*240 LCD Screen LCD for Handheld
ET0350A6DM6 LCD Panel Product details :
| Brand | EDT |
| Model P/N | ET0350A6DM6 |
| Diagonal Size | 3.5" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 320(RGB)×240, QVGA 115PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 70.08(W)×52.56(H) mm |
| Bezel Opening | 73.2(W)×55.7(H) mm |
| Outline Size | 76.8(W)×63.8(H)×3.6(D) mm |
| Surface | - |
| Brightness | 450 cd/m² (Typ.) |
| Contrast Ratio | 450:1 (Typ.) (TM) |
| Viewing Angle | 75/75/75/75 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 6 o'clock |
| Response Time | 15/35 (Typ.)(Tr/Td) |
| Display Colors | 16.7M 61%NTSC |
| Lamp Type | 6S1PWLED, 40K hours, Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | - |
| Application | Handheld & PDA |
| Signal Interface | Serial RGB (8-bit) + SPI, 24 pinsFPC |
| Input Voltage | 3.3/3.3V (Typ.)(VCC/VDD) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| 3.5 inch ET0350A6DM6 320*240 LCD Screen LCD for Handheld | |
ET0350A6DM6 LCD Display Features :
High Quality:
Highest quality touch LCD screen replacement parts.
Repair Utility:
Suitable for repairing faulty screens, touch screen problems, dead pixels, cracked touchscreens, and other related issues.
Thorough Testing:
Each assembly is tested before shipping to ensure 100% functionality.
Quality control includes checks for dark spots, color points, and dead pixels, ensuring no defects.
ET0350A6DM6 LCD Panel Shipping and Package :
ET0350A6DM6 LCD Display Shipping Policy :
Shipping Method:
If the buyer selects a specific courier (e.g., FedEx), we may ship the product using an equivalent service level from other logistics companies such as DHL, UPS, TNT, or others.
Specified Logistics:
If you require a specific logistics company, please inform us in advance.
ET0350A6DM6 LCD Display Return Policy :
Product Status:
The product's condition (new or old) will be indicated in the product title.
Return and Exchange Conditions:
If the product encounters quality problems within 30 days of receipt, we offer free returns and exchanges.
Return Procedure:
When returning the product, please provide a detailed explanation of the issues encountered.
Include actual photos showing the problems with the product.
ET0350A6DM6 LCD Panel FAQ :
Q: If I place order now,when will you ship the goods of ET0350A6DM6 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Can you give me a discount if I need a large quantity of ET0350A6DM6 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How long will I receive my goods ET0350A6DM6 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How to make payment of ET0350A6DM6 ?
A: We accept T/T , Paypal , western union .
Want to Know more details about this product
