in stock 10.0 inch HSD100GBN1-A00 1200*1600 30 pins LCD Display
Product Details:
Place of Origin: | China |
Brand Name: | HannStar |
Model Number: | HSD100GBN1-A00 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Original packaging/conventional packaging box |
Delivery Time: | 7 Days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 100000 Unit/Units per Month |
Detail Information |
|||
Model Name: | HSD100GBN1-A00 | Diagonal Size: | 10.0" |
---|---|---|---|
Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 1200(RGB)×1600 199PPI |
Pixel Format: | RGB Vertical Stripe | Active Area: | 152.46(W)×203.28(H) Mm |
Used For: | Pad & Tablet、Industrial | Touch Panel: | Without |
Product Description
in stock 10.0 inch HSD100GBN1-A00 1200*1600 30 pins LCD Display
HSD100GBN1-A00 LCD Panel Product details :
Brand | HannStar |
Model P/N | HSD100GBN1-A00 |
Diagonal Size | 10.0" |
Panel Type | a-Si TFT-LCD, LCM |
Resolution | 1200(RGB)×1600 199PPI |
Pixel Format | RGB Vertical Stripe |
Active Area | 152.46(W)×203.28(H) mm |
Bezel Opening | - |
Luminance | - |
Contrast Ratio | 15:1 (Typ.) (RF) |
View Direction | - |
Response Time | 5 (Typ.)(Tr+Td) |
Viewing Angle | 60/60/60/60 (Typ.)(CR≥2) |
Operating Mode | TN, Normally White, Reflective |
Support Color | 16.7M |
Light Source | WLED [4 strings], 15K hours, W/O Driver |
Weight | TBD |
Designed For | Pad & Tablet,Industrial |
Frame Rate | 60Hz |
Touch Panel | Without |
Interface Type | MIPI (4 data lanes), 30 pinsFPC |
Power Supply | 1.8/3.3V (Typ.)(IOVCC/VCI) |
Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
in stock 10.0 inch HSD100GBN1-A00 1200*1600 30 pins LCD Display |
HSD100GBN1-A00 LCD Panel Shipping and Package :
HSD100GBN1-A00 LCD Panel FAQ :
Q: How to do if I can't find the screen that I require in your listings?
A: We should have it in stock , please contact us directly.if we dont't have it , we can try our best to find it for you .
Q: Why big order delivery time are long?
A: All the lcd panel are Strictly tested before shipment , to ensure that you receive good quality lcd panel and work well!
Q:Can you declared low value for my order when shipping?
A:Yes, We can do it for you if you need.
Q: What happen if the lcd panel HSD100GBN1-A00 I received can't work ?
A: All the goods will be tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
