HSD070GWW5-900001-PX 7.0 inch 800*1280 LCD Screen Module
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD070GWW5-900001-PX |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | HSD070GWW5-900001-PX | Diagonal Size: | 7.0" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 800(RGB)×1280, WXGA 215PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 94.2(W)×150.72(H) Mm |
| Used For: | Industrial | Touch Panel: | Without |
Product Description
HSD070GWW5-900001-PX 7.0 inch 800*1280 LCD Screen Module
HSD070GWW5-900001-PX LCD Panel Product details :
| Brand | HannStar |
| Model P/N | HSD070GWW5-900001-PX |
| Diagonal Size | 7.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 800(RGB)×1280, WXGA 215PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 94.2(W)×150.72(H) mm |
| Bezel Opening | - |
| Outline Dim. | 99.75(H)×161.6(V)×2.55(D) mm |
| Treatment | Antiglare |
| Luminance | 350 cd/m² (Typ.) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 10/20 (Typ.)(Tr/Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Operating Mode | IPS Pro, Normally Black, Transmissive |
| Support Color | 16.7M 60%NTSC |
| Light Source | WLED [5S4P], 20K hours, W/O Driver |
| Weight | 79.5g (Typ.) |
| Designed For | Industrial |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | MIPI (4 data lanes), 30 pinsConnector |
| Power Supply | 1.8/5.5/-5.5V (Typ.)(VDDIN/AVDD/AVEE) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| HSD070GWW5-900001-PX 7.0 inch 800*1280 LCD Screen Module | |
