NEW 1280*800 TM101JVHG42-00 430 cd/m2 TFT-LCD Panel Screen

Brand Name:	TIANMA
Model Number:	TM101JVHG42-00
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

TM101JVHG42-00

Diagonal Size:

10.1"

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

1280(RGB)×800, WXGA 149PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

216.96(W)×135.6(H) Mm

Designed For:

Industrial、Automotive Display

Frame Rate:

Supply Ability:

100000 Unit/Units per Month

Product Description

NEW 1280*800 TM101JVHG42-00 430 cd/m2 TFT-LCD Panel Screen

TM101JVHG42-00 LCD Panel Product details :

Brand	TIANMA
Model P/N	TM101JVHG42-00
Diagonal Size	10.1"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1280(RGB)×800, WXGA 149PPI
Pixel Format	RGB Vertical Stripe
Active Area	216.96(W)×135.6(H) mm
Bezel Opening	-
Outline Size	256(W)×170(H)×10(D) mm
Surface	Antiglare, Hard coating (6H)
Brightness	430 cd/m² (Typ.)
Contrast Ratio	1000:1 (Typ.) (TM)
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)
Display Mode	SFT, Normally Black, Transmissive
Best View on	Symmetry
Response Time	25 (Typ.)(Tr+Td)
Display Colors	262K/16.7M 50%NTSC
Lamp Type	WLED, 50K hours, With LED Driver
Frequency	60Hz
Touch Screen	PCAP, USB
Panel Weight	543g (Typ.)
Application	Industrial,Automotive Display
Signal Interface	LVDS (1 ch, 6/8-bit), 30 pinsConnector
Input Voltage	3.3V (Typ.)
Environment	Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C
