5.7 inch 1440*2560 LPP057A386A lcd Screen Display for Mobile Phone
Product Details:
| Place of Origin: | China |
| Brand Name: | JDI |
| Model Number: | LPP057A386A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LPP057A386A | Diagonal Size: | 5.7" |
|---|---|---|---|
| Panel Type: | LTPS TFT-LCD, CELL, Full Cell | Resolution: | 1440(RGB)×2560, Quad-HD 515PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 70.956(W)×126.144(H) Mm |
| Used For: | Mobile Phone | Input Voltage: | 1.8/3.1/5.5/-5.5V (Typ.)(VDDI/VDDH/AVDD/AVEE) |
| Signal Interface: | MIPI (4 Data Lanes) | Environment: | Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 80 °C |
Product Description
5.7 inch 1440*2560 LPP057A386A lcd Screen Display for Mobile Phone
LPP057A386A LCD Panel Product details :
| Brand | JDI |
| Model P/N | LPP057A386A |
| Diagonal Size | 5.7" |
| Panel Type | LTPS TFT-LCD, CELL, Full Cell |
| Resolution | 1440(RGB)×2560, Quad-HD 515PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 70.956(W)×126.144(H) mm |
| Bezel Opening | - |
| Outline Size | 72.956(W)×132.604(H)×0.62(D) mm |
| Surface | With Polarizer, Hard coating |
| Brightness | 0 cd/m² |
| Contrast Ratio | 1400:1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) |
| Display Mode | IPS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Glass Depth | 0.20+0.20 mm |
| Transmissivity | 4.13% (Typ.)(with Polarizer) |
| Display Colors | 16.7M 95%NTSC |
| Lamp Type | No B/L |
| Frequency | 60Hz |
| Touch Screen | PCAP |
| Driver IC | COG Suggest JD36850H-DP/3YC |
| Panel Weight | 13.8g (Typ.) |
| Application | Mobile Phone |
| Signal Interface | MIPI (4 data lanes) |
| Input Voltage | 1.8/3.1/5.5/-5.5V (Typ.)(VDDI/VDDH/AVDD/AVEE) |
| Environment | Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 80 °C |
LPP057A386A LCD Display Features :
High Quality:
Highest quality touch LCD screen replacement parts.
Repair Utility:
Suitable for repairing faulty screens, touch screen problems, dead pixels, cracked touchscreens, and other related issues.
Thorough Testing:
Each assembly is tested before shipping to ensure 100% functionality.
Quality control includes checks for dark spots, color points, and dead pixels, ensuring no defects.
LPP057A386A LCD Panel Shipping and Package :
LPP057A386A LCD Display Shipping Policy :
Shipping Method:
If the buyer selects a specific courier (e.g., FedEx), we may ship the product using an equivalent service level from other logistics companies such as DHL, UPS, TNT, or others.
Specified Logistics:
If you require a specific logistics company, please inform us in advance.
LPP057A386A LCD Display Return Policy :
Product Status:
The product's condition (new or old) will be indicated in the product title.
Return and Exchange Conditions:
If the product encounters quality problems within 30 days of receipt, we offer free returns and exchanges.
Return Procedure:
When returning the product, please provide a detailed explanation of the issues encountered.
Include actual photos showing the problems with the product.
LPP057A386A LCD Panel FAQ :
Q: Can I pay my order of LPP057A386A via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can you give me a discount if I need a large quantity of LPP057A386A ?
A: Of course!If you make a large order, we will give you a discount.
Q: How can I trace my order of LPP057A386A ?
A: we will give you tracking number then you can trace your order from website.
Q: Do you accept sample orders of LPP057A386A ?
A: Of course!sample order is welcome !
Want to Know more details about this product
