MV230FHM-N40 23.0 inch 1920*1080 lcd Screen Monitor

Brand Name:	BOE
Model Number:	MV230FHM-N40
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin:

China

Model Name:

MV230FHM-N40

Diagonal Size:

23.0"

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

1920(RGB)×1080, FHD 95PPI

Pixel Format:

RGBW Vertical Stripe

Active Area:

509.184(W)×286.416(H) Mm

Used For:

Desktop Monitor

Interface Type:

LVDS (2 Ch, 8-bit)30 Pins Connector

Contrast Ratio:

1000:1 (Min.) (TM)

Light Source:

WLED, 30K Hours , W/O Driver

Supply Ability:

100000 Unit/Units per Month

Product Description

MV230FHM-N40 23.0 inch 1920*1080 lcd Screen Monitor

MV230FHM-N40 LCD Panel Product details :

Brand	BOE
Model P/N	MV230FHM-N40
Diagonal Size	23.0"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1920(RGB)×1080, FHD 95PPI
Pixel Format	RGB Vertical Stripe
Active Area	509.184(W)×286.416(H) mm
Bezel Opening	-
Outline Dim.	517.2(W)×302.8(H)×12.8(D) mm
Luminance	250 cd/m² (Typ.)
View Direction	Symmetry
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)
Support Color	16.7M 72% NTSC
Weight	2.10Kgs
Frame Rate	60Hz
Treatment	Antiglare (Haze 25%), Hard coating (3H)
Contrast Ratio	1000:1 (Min.) (TM)
Response Time	14 (Typ.)(G to G)
Operating Mode	ADS, Normally Black, Transmissive
Light Source	WLED, 30K hours , W/O Driver
Designed For	Desktop Monitor
Touch Panel	Without
Interface Type	LVDS (2 ch, 8-bit)30 pins Connector
Power Supply	5.0V (Typ.)
Environment	Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 60 °C

MV230FHM-N40 LCD Display Features :

High Quality:

Highest quality touch LCD screen replacement parts.

Repair Utility:

Suitable for repairing faulty screens, touch screen problems, dead pixels, cracked touchscreens, and other related issues.

Thorough Testing:

Each assembly is tested before shipping to ensure 100% functionality.

Quality control includes checks for dark spots, color points, and dead pixels, ensuring no defects.

MV230FHM-N40 LCD Panel Shipping and Package :

MV230FHM-N40 23.0 inch 1920*1080 lcd Screen Monitor 0

MV230FHM-N40 LCD Display Shipping Policy :

Shipping Method:

If the buyer selects a specific courier (e.g., FedEx), we may ship the product using an equivalent service level from other logistics companies such as DHL, UPS, TNT, or others.

Specified Logistics:

If you require a specific logistics company, please inform us in advance.

MV230FHM-N40 LCD Display Return Policy :

Product Status:

The product's condition (new or old) will be indicated in the product title.

Return and Exchange Conditions:

If the product encounters quality problems within 30 days of receipt, we offer free returns and exchanges.

Return Procedure:

When returning the product, please provide a detailed explanation of the issues encountered.

Include actual photos showing the problems with the product.

MV230FHM-N40 LCD Panel FAQ :

Q: Can You declare my order of MV230FHM-N40 to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .

Q: How long is the warranty ?

A: We offer 90days warranty .

Q: Can I pay my order of MV230FHM-N40 via credit card ?

A: Yes!you can use your credit card through your Paypal account.

Q: How long will I receive my goods MV230FHM-N40 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
