NEW 9.0 inch T-55311D090J-FW-A-ADN 800*480 60Hz LCD Panel Industrial
Product Details:
| Place of Origin: | China |
| Brand Name: | OPTREX |
| Model Number: | T-55311D090J-FW-A-ADN |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | T-55311D090J-FW-A-ADN | Diagonal Size: | 9.0" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 800(RGB)×480, WVGA 103PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 196.8(W)×118.08(H) Mm |
| Designed For: | Industrial | Touch Screen: | Without |
Product Description
NEW 9.0 inch T-55311D090J-FW-A-ADN 800*480 60Hz LCD Panel Industrial
T-55311D090J-FW-A-ADN LCD Panel Product details :
| Brand | OPTREX |
| Model P/N | T-55311D090J-FW-A-ADN |
| Diagonal Size | 9.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 800(RGB)×480, WVGA 103PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 196.8(W)×118.08(H) mm |
| Bezel Opening | 199.4(W)×120.7(H) mm |
| Outline Dim. | 225(W)×142.2(H)×17.5(D) mm |
| Luminance | 600 cd/m² (Typ.) |
| View Direction | 6 o'clock |
| Viewing Angle | 80/80/80/60 (Typ.)(CR≥10) |
| Support Color | 262K/16.7M 40% NTSC |
| Weight | 730g (Typ.) |
| Frame Rate | 60Hz |
| Treatment | Hard coating (6H), Antireflection |
| Contrast Ratio | 600:1 (Typ.) (TM) |
| Response Time | 4/12 (Typ.)(Tr/Td) |
| Operating Mode | TN, Normally White, Transmissive |
| Light Source | CCFL [2 pcs] , 50K hours , W/O Driver |
| Designed For | Industrial |
| Touch Panel | Without |
| Interface Type | LVDS (1 ch, 6/8-bit)20 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -20 ~ 70 °C; Storage Temperature: -20 ~ 80 °C |
| NEW 9.0 inch T-55311D090J-FW-A-ADN 800*480 60Hz LCD Panel Industrial | |
