AM-1920720B4TZQW-12H 12.3 inch 60Hz LCD Screen Display Panel

All Category

Floor Standing Digital Signage

AM-1920720B4TZQW-12H 12.3 inch 60Hz LCD Screen Display Panel

Brand Name:	AMPIRE
Model Number:	AM-1920720B4TZQW-12H
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

AM-1920720B4TZQW-12H

Diagonal Size:

12.3"

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

1920(RGB)×720 167PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

292.032(W)×109.512(H) Mm

Frame Rate:

Used For:

Outdoor High Brightness、Automotive Display

Supply Ability:

100000 Unit/Units per Month

Product Description

AM-1920720B4TZQW-12H 12.3 inch 60Hz LCD Screen Display Panel

AM-1920720B4TZQW-12H LCD Panel Product details :

Brand	AMPIRE
Model P/N	AM-1920720B4TZQW-12H
Diagonal Size	12.3"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1920(RGB)×720 167PPI
Pixel Format	RGB Vertical Stripe
Active Area	292.032(W)×109.512(H) mm
Bezel Opening	294.8(W)×112.1(H) mm
Outline Size	308.1(W)×130(H)×15.6(D) mm
Brightness	850 cd/m² (Typ.)
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)
Best View on	Symmetry
Display Colors	16.7M 100%sRGB
Frequency	60Hz
Weight	TBD
Surface	Glare (Haze 0%)
Contrast Ratio	1100:1 (Typ.) (TM)
Display Mode	IPS, Normally Black, Transmissive
Response Time	30 (Typ.)(Tr+Td)
Lamp Type	11S4P WLED , 30K hours , With LED Driver
Touch Screen	Without
Application	Outdoor High Brightness,Automotive Display
Signal Interface	LVDS (2 ch, 8-bit), 40 pinsConnector
Input Voltage	3.3V (Typ.)
Environment	Operating Temp.: -30 ~ 85 °C ;Storage Temp.: -40 ~ 85 °C; Vibration Level: 2.9G (28.4 m/s²)
AM-1920720B4TZQW-12H 12.3 inch 60Hz LCD Screen Display Panel

AM-1920720B4TZQW-12H LCD Panel Note :

Model Verification:

Please ensure that the model number you need is exactly the same as the model number you have ordered. We will ship the LCD panel based strictly on the model specified in your order. Ensuring the correct model number is crucial to avoid any compatibility issues.

Comprehensive Testing:

We conduct 100% testing on each LCD panel to ensure it meets our stringent quality standards. This thorough testing process guarantees that you receive a fully functional and reliable product. Our commitment to quality ensures that each panel is meticulously checked before it is shipped to you.

AM-1920720B4TZQW-12H LCD Panel Shipping and Package :

AM-1920720B4TZQW-12H 12.3 inch 60Hz LCD Screen Display Panel 0

AM-1920720B4TZQW-12H LCD Panel Shipping Guidelines:

Address Confirmation:

It is crucial to verify that the shipping address provided in your order is accurate. We will ship the LCD panel to the address listed in the order. If you need the panel to be shipped to a different address, please email us the new address immediately after making the payment to avoid any shipping errors.

Shipment Timeline:

Your order will be processed and shipped within three business days after we have received your payment. Please note that business days do not include weekends or public holidays, so take this into account when estimating your delivery date.

AM-1920720B4TZQW-12H LCD Panel ESTIMATED DELIVERY TIME :

Standard Shipping:

The estimated delivery time for standard shipping is between 10 to 35 working days. This timeframe may vary depending on the destination and other factors such as customs processing and local postal services.

Expedited Shipping:

For a faster delivery option, expedited shipping is available with an estimated delivery time of 4 to 7 working days. This option is ideal if you need the LCD panel urgently and prefer a quicker shipping method.

AM-1920720B4TZQW-12H LCD Panel FAQ :

Q: Can You declare my order of AM-1920720B4TZQW-12H a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .

Q: Can you give me a discount if I need a large quantity of AM-1920720B4TZQW-12H ?

A: Of course!If you make a large order, we will give you a discount.

Q: Do you accept sample orders of AM-1920720B4TZQW-12H ?

A: Of course!sample order is welcome !

Q: Can I pay my order of AM-1920720B4TZQW-12H via credit card ?

A: Yes!you can use your credit card through your Paypal account.
