Brand Name: | AMPIRE |
Model Number: | AM-800480STMQW-A0 |
MOQ: | 1 pcs |
Price: | Negotiable |
Packaging Details: | Original packaging/conventional packaging box |
Payment Terms: | T/T, Western Union |
AM-800480STMQW-A0 7.0 inch 60Hz LCD Screen LCD Panel
AM-800480STMQW-A0 LCD Panel Product details :
Brand | AMPIRE |
Model P/N | AM-800480STMQW-A0 |
Diagonal Size | 7.0" |
Panel Type | a-Si TFT-LCD, LCM |
Resolution | 800(RGB)×480, WVGA 133PPI |
Pixel Format | RGB Vertical Stripe |
Active Area | 152.4(W)×91.44(H) mm |
Bezel Opening | 155.3(W)×94.30(H) mm |
Outline Size | 165(W)×104.44(H)×8.26(D) mm |
Treatment | - |
Luminance | 350 cd/m² (Typ.) |
Contrast Ratio | 400 : 1 (Typ.) (TM) |
Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) |
Response | 5/11 (Typ.)(Tr/Td) ms |
Good View at | 6 o'clock |
Work Mode | TN, Normally White, Transmissive |
Color Depth | 262K 48%NTSC |
Backlight | 3S8PWLED, 20K hours, No Driver |
Mass | 135g (Typ.) |
Used for | Automotive Display |
Refresh Rate | 60Hz |
Touchscreen | Without |
Signal Type | LVDS (1 ch, 6-bit), 20 pinsConnector |
Voltage Supply | 3.3V (Typ.) |
Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
AM-800480STMQW-A0 7.0 inch 60Hz LCD Screen LCD Panel |
AM-800480STMQW-A0 LCD Panel Shipping and Package :
AM-800480STMQW-A0 LCD Panel FAQ :
Q: How long is the warranty of AM-800480STMQW-A0 ?
A: NEW Product warranty is 90 days.
Q: How to order lcd panel AM-800480STMQW-A0 ?
A: Tell us the quantity you need ,Then we will make a PI for you to confirm the order details ,When we confirmed everything, you can arrange the payment ,After we received the payment, we will ship goods to you within 1-2day.
Q: How to do if I can't find the screen that I require in your listings?
A: We should have it in stock , please contact us directly.if we dont't have it , we can try our best to find it for you .
Q: What does "We may ship a 100% compatible part number for your screen" mean?
A: Because some original screens are not available in the market , So we send the compatible item to you .Don't worry , it is 100% compatible for your screen.
