TM050JYHP06 5.0 inch 720*1280 LCD Screen Display Panel

Brand Name:	TIANMA
Model Number:	TM050JYHP06
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

TM050JYHP06

Diagonal Size:

Panel Type:

A-Si TFT-LCD, CELL, Full Cell

Resolution:

720(RGB)×1280, WXGA 294PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

62.1(W)×110.4(H) Mm

Lamp Type:

No B/L

Application:

Mobile Phone

Driver IC:

COGSuggest HX8394-A00 A01 B C D, NT3520 1, OTM1283A S6D7AA0

Environment:

Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 80 °C

Supply Ability:

100000 Unit/Units per Month

Product Description

TM050JYHP06 5.0 inch 720*1280 LCD Screen Display Panel

TM050JYHP06 LCD Panel Product details :

Brand	TIANMA
Model P/N	TM050JYHP06
Diagonal Size	5.0"
Panel Type	a-Si TFT-LCD, CELL, Full Cell
Resolution	720(RGB)×1280, WXGA 294PPI
Pixel Format	RGB Vertical Stripe
Active Area	62.1(W)×110.4(H) mm
Bezel Opening	-
Outline Size	64.5(W)×117.59(H)×0.4(D) mm
Brightness	0 cd/m²
Viewing Angle	80/80/80/80 (Typ.)(CR≥10)
Best View on	Symmetry
Glass Depth	0.20+0.20 mm
Display Colors	16.7M 70%NTSC
Frequency	-
Weight	-
Surface	Without Polarizer
Contrast Ratio	900:1 (Typ.) (TM)
Display Mode	SFT, Normally Black, Transmissive
Response Time	30 (Typ.)(Tr+Td)
Transmissivity	4.6% (Typ.)
Lamp Type	No B/L
Touch Screen	Without
Application	Mobile Phone
Driver IC	COGSuggest HX8394-A00 A01 B C D, NT3520 1, OTM1283A S6D7AA0
Environment	Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 80 °C

TM050JYHP06 LCD Panel Shipment :

· We're not responsible for any accidents delays or other issues that are the resposibility of the shipping service.But we will help you to track the package until you get.

· Please make sure to double check your address before completing your payment.

· An email will be sent as package is process for shipment .We will provide tracking number for you to check the package online.

· Customers are responsible for customs taxes and duties where applicable.

· Any import charges or fees are the buyer's responsibility. If the package can't be delivered because of the buyers reason(including refusing to sign), buyer should afford all the extra cost!

TM050JYHP06 LCD Panel Shipping and Package :

TM050JYHP06 5.0 inch 720*1280 LCD Screen Display Panel 0

TM050JYHP06 LCD Panel Shipment Information :

Shipment Policies

Responsibility for Delays and Issues: While we are committed to helping you track your package, please note that we are not responsible for any accidents, delays, or other issues that are the responsibility of the shipping service. We will, however, assist you in tracking your package until it reaches you.

Address Verification: It is crucial to double-check your shipping address before completing your payment. Ensuring that the address is accurate helps prevent delivery issues and delays.

Shipping Notification: Once your package is processed for shipment, you will receive an email notification. This email will include the tracking number, which you can use to monitor your package's status online.

Customs Taxes and Duties: Customers are responsible for any customs taxes and duties applicable in their country. Please be aware of your local regulations regarding import charges to avoid unexpected fees.

Import Charges: Any additional import charges or fees imposed by your country are the buyer's responsibility. If a package cannot be delivered due to reasons attributable to the buyer (such as refusal to sign for the package), the buyer will be responsible for any additional costs incurred.

TM050JYHP06 LCD Panel Return and Warranty Information :

Return Policy

Inspection and Exchange: All goods undergo two inspections before shipment to guarantee quality. If you are not satisfied with your purchase, you may exchange the item within one week. To initiate an exchange, please contact us within 24 hours of receiving your purchase.

Condition of Return Items: Items must be returned in their original condition, including the box and all accessories. Items showing signs of man-made defects, such as breakage or scratches, are not eligible for return or exchange.

Return Shipping: For returning any items, please use EMS (Express Mail Service) or your local postal service to send the item back to us.

Warranty Policy

Warranty Duration: All items come with a six-month warranty, covering any issues not caused by human error or damage. If your item has a defect not caused by man-made problems, we will replace it for you free of charge.

Best After-Sale Service: We pride ourselves on providing excellent after-sale service. Should any problems arise, we are dedicated to resolving them to ensure customer satisfaction.

TM050JYHP06 LCD Panel FAQ :

Q: How do you ship my goods TM050JYHP06 ?

A: We can shipping all over the world.via DHL,UPS,Fedex and EMS, the packaging is very safe and strong.

Q: How long is the warranty of TM050JYHP06 ?

A: 90 days warranty .

Q: How can I trace my order of TM050JYHP06 ?

A: we will give you tracking number then you can trace your order form website.

Q: Can you give me a discount if I need a large quantity of TM050JYHP06 ?

A: Of course!If you make a large order, we will give you a discount.
