LCD Screen Display Panel

LS050T1SC01S 5.0 inch 1080*1920 LCD Screen for Mobile Phone

All Category

Floor Standing Digital Signage

LS050T1SC01S 5.0 inch 1080*1920 LCD Screen for Mobile Phone

Brand Name:	Sharp
Model Number:	LS050T1SC01S
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

LS050T1SC01S

Diagonal Size:

Panel Type:

CG-Silicon, LCM

Resolution:

1080(RGB)×1920, FHD 445PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

61.641(W)×109.584(H) Mm

Response Time:

35 (Max.)(Tr+Td)

Application:

Mobile Phone

Frame Rate:

Interface Type:

MIPI (4 Data Lanes), 31 PinsFPC

Supply Ability:

100000 Unit/Units per Month

Product Description

LS050T1SC01S 5.0 inch 1080*1920 LCD Screen for Mobile Phone

LS050T1SC01S LCD Panel Product details :

Brand	Sharp
Model P/N	LS050T1SC01S
Diagonal Size	5.0"
Panel Type	CG-Silicon, LCM
Resolution	1080(RGB)×1920, FHD 445PPI
Pixel Format	RGB Vertical Stripe
Active Area	61.641(W)×109.584(H) mm
Bezel Opening	-
Outline Dim.	64.04(H)×116.9(V)×1.33(D) mm
Treatment	Hard coating (3H)
Luminance	500 cd/m² (Typ.)
Contrast Ratio	1000:1 (Typ.) (TM)
View Direction	Symmetry
Response Time	35 (Max.)(Tr+Td)
Viewing Angle	80/80/80/80 (Typ.)(CR≥100)
Operating Mode	New Mode2, Normally Black, Transmissive
Support Color	16.7M 80%NTSC
Light Source	WLED [6S2P], W/O Driver
Weight	20.0g (Typ.)
Designed For	Mobile Phone
Frame Rate	60Hz
Touch Panel	Without
Interface Type	MIPI (4 data lanes), 31 pinsFPC
Power Supply	1.8/5.0/-5.0V (Typ.)(IOVDD/AVDD+/AVDD-)
Environment	Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C
New 5.0 inch LCD Display LS050T1SC01S FHD 500 cd/m2 LCD Screen
