LCD Screen Display Panel

6.1 inch 800*480 TM061RFH01 40 pins LCD Screen Display

All Category

Floor Standing Digital Signage

6.1 inch 800*480 TM061RFH01 40 pins LCD Screen Display

Brand Name:	TIANMA
Model Number:	TM061RFH01
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin:

China

Model Name:

TM061RFH01

Diagonal Size:

Panel Type:

A-Si TFT-LCD, CELL, FOG

Resolution:

800(RGB)×480, WVGA 154PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

133.44(W)×76.32(H) Mm

Best View On:

12 O'clock

Application:

Portable Navigation

Input Voltage:

3.3/8.1/22.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL)

Environment:

Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 80 °C

Supply Ability:

100000 Unit/Units per Month

Product Description

6.1 inch 800*480 TM061RFH01 40 pins LCD Screen Display

TM061RFH01 LCD Panel Product details :

Brand	TIANMA
Model P/N	TM061RFH01
Diagonal Size	6.1"
Panel Type	a-Si TFT-LCD, CELL, FOG
Resolution	800(RGB)×480, WVGA 154PPI
Pixel Format	RGB Vertical Stripe
Active Area	133.44(W)×76.32(H) mm
Bezel Opening	-
Outline Size	141(W)×87(H)×1.43(D) mm
Surface	Antiglare
Brightness	0 cd/m²
Contrast Ratio	500:1 (Typ.) (TM)
Viewing Angle	70/70/60/70 (Typ.)(CR≥10)
Display Mode	TN, Normally White, Transmissive
Best View on	12 o'clock
Response Time	25 (Typ.)(Tr+Td)
Glass Depth	0.50+0.50 mm
Transmissivity	4.8% (Typ.)(with Polarizer)
Display Colors	262K 50%NTSC
Lamp Type	No B/L, Without Driver
Frequency	60Hz
Touch Screen	Without
Driver IC	COGBuilt-in 1 source chips
Panel Weight	TBD
Application	Portable Navigation
Signal Interface	Parallel RGB (1 ch, 6-bit), 40 pins FPC
Input Voltage	3.3/8.1/22.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL)
Environment	Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 80 °C

TM061RFH01 LCD Panel Shipment :

· We're not responsible for any accidents delays or other issues that are the resposibility of the shipping service.But we will help you to track the package until you get.

· Please make sure to double check your address before completing your payment.

· An email will be sent as package is process for shipment .We will provide tracking number for you to check the package online.

· Customers are responsible for customs taxes and duties where applicable.

· Any import charges or fees are the buyer's responsibility. If the package can't be delivered because of the buyers reason(including refusing to sign), buyer should afford all the extra cost!

TM061RFH01 LCD Panel Shipping and Package :

6.1 inch 800*480 TM061RFH01 40 pins LCD Screen Display 0

TM061RFH01 LCD Panel Shipment Information :

Shipment Policies

Responsibility for Delays and Issues: While we are committed to helping you track your package, please note that we are not responsible for any accidents, delays, or other issues that are the responsibility of the shipping service. We will, however, assist you in tracking your package until it reaches you.

Address Verification: It is crucial to double-check your shipping address before completing your payment. Ensuring that the address is accurate helps prevent delivery issues and delays.

Shipping Notification: Once your package is processed for shipment, you will receive an email notification. This email will include the tracking number, which you can use to monitor your package's status online.

Customs Taxes and Duties: Customers are responsible for any customs taxes and duties applicable in their country. Please be aware of your local regulations regarding import charges to avoid unexpected fees.

Import Charges: Any additional import charges or fees imposed by your country are the buyer's responsibility. If a package cannot be delivered due to reasons attributable to the buyer (such as refusal to sign for the package), the buyer will be responsible for any additional costs incurred.

TM061RFH01 LCD Panel Return and Warranty Information :

Return Policy

Inspection and Exchange: All goods undergo two inspections before shipment to guarantee quality. If you are not satisfied with your purchase, you may exchange the item within one week. To initiate an exchange, please contact us within 24 hours of receiving your purchase.

Condition of Return Items: Items must be returned in their original condition, including the box and all accessories. Items showing signs of man-made defects, such as breakage or scratches, are not eligible for return or exchange.

Return Shipping: For returning any items, please use EMS (Express Mail Service) or your local postal service to send the item back to us.

Warranty Policy

Warranty Duration: All items come with a six-month warranty, covering any issues not caused by human error or damage. If your item has a defect not caused by man-made problems, we will replace it for you free of charge.

Best After-Sale Service: We pride ourselves on providing excellent after-sale service. Should any problems arise, we are dedicated to resolving them to ensure customer satisfaction.

TM061RFH01 LCD Panel FAQ :

Q: What happen if the TM061RFH01 I receive can't work ?

A: The TM061RFH01 will be tested strictly before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.

Q: Can You declare my order of lcd panel TM061RFH01 at a very low value ?

A: Yes , we can . pls inform us before shipping .

Q: How long is the warranty of TM061RFH01 ?

A: 90days warranty .

Q: Are you manufactory or trade company ?

A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
