1080*1920 LX055A1BB10 5.5 inch LCD Screen FOR Mobile Phone
Product Details:
| Place of Origin: | China |
| Brand Name: | Sharp |
| Model Number: | LX055A1BB10 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LX055A1BB10 | Diagonal Size: | 5.5" |
|---|---|---|---|
| Panel Type: | CG-Silicon, CELL, Q-CUT (Full Cell) | Resolution: | 1080(RGB)×1920, FHD 403PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 68.04(W)×120.96(H) Mm |
| Designed For: | Mobile Phone | Touch Panel: | On-Cell Touch |
| Viewing Angle: | 80/80/80/80 (Typ.)(CR≥10) | Operating Mode: | New Mode2, Normally Black, Transmissive |
Product Description
1080*1920 LX055A1BB10 5.5 inch LCD Screen FOR Mobile Phone
LX055A1BB10 LCD Panel Product details :
| Brand | Sharp |
| Model P/N | LX055A1BB10 |
| Diagonal Size | 5.5" |
| Panel Type | CG-Silicon, CELL, Q-CUT (Full Cell) |
| Resolution | 1080(RGB)×1920, FHD 403PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 68.04(W)×120.96(H) mm |
| Bezel Opening | - |
| Outline Dim. | 69.44(W)×126.86(H)×0.3(D) mm |
| Treatment | Without Polarizer |
| Luminance | 0 cd/m² |
| Contrast Ratio | 1300:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 35 (Max.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Operating Mode | New Mode2, Normally Black, Transmissive |
| Plate Thickness | 0.15+0.15 mm |
| Transmittance | 3.74% (Typ.)(with Polarizer) |
| Support Color | 83%NTSC |
| Light Source | No B/L |
| Weight | 5.60g (Typ.) |
| Designed For | Mobile Phone |
| Frame Rate | 60Hz |
| Touch Panel | On-Cell Touch |
| D-IC Detail | COG Suggest FT8716, FT8736 |
| Environment | Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| Touch Panel LX055A1BB10 Suppliers 5.5 inch 1080*1920 LCD Panel Screen | |
LX055A1BB10 LCD Panel Shipping and Package :
We strive to ensure that every customer is 100% satisfied, solve any problems for you, and always leave positive feedback to all customers.
If you are satisfied with the project, please leave us positive feedback and 5 DSRs.
Before contacting us, please do not open the box or leave negative/natural feedback.
All issues can be resolved through communication.
Thank you very much and have a pleasant day!
If you have any questions, please feel free to contact us at any time. Your question will be answered within 24 hours.
If you do not receive a reply within 24 hours, please open your email and check if there is a reply in the spam folder
LX055A1BB10 LCD Panel FAQ :
Q: Do you accept sample orders of LX055A1BB10 ?
A: Of course!sample order is welcome !
Q: Can you give me a discount if I need a large quantity of LX055A1BB10 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How long will I receive my goods LX055A1BB10 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: Can I pay my order of LX055A1BB10 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
