Original 5.5 inch HSD055BHW7-P00 LCD Screen Monitor

Brand Name:	HannStar
Model Number:	HSD055BHW7-P00
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

HSD055BHW7-P00

Diagonal Size:

Panel Type:

A-Si TFT-LCD, CELL, Q-CUT (Full Cell)

Resolution:

720(RGB)×1440 295PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

61.884(W)×123.768(H) Mm

Designed For:

Mobile Phone

Light Source:

No B/L

D-IC Detail:

COG Suggest OTM1287A, OTM1289A, OTM1290A, HX8394-F, ILI9881C, NT35521S, NT35521Z, JD9365D

Environment:

Operating Temperature: -20 ~ 70 °C; Storage Temperature: -30 ~ 80 °C

Supply Ability:

100000 Unit/Units per Month

Product Description

Original 5.5 inch HSD055BHW7-P00 LCD Screen Monitor

HSD055BHW7-P00 LCD Panel Product details :

Brand	HannStar
Model P/N	HSD055BHW7-P00
Diagonal Size	5.5"
Panel Type	a-Si TFT-LCD, CELL, Q-CUT (Full Cell)
Resolution	720(RGB)×1440 295PPI
Pixel Format	RGB Vertical Stripe
Active Area	61.884(W)×123.768(H) mm
Bezel Opening	-
Outline Dim.	63.884(W)×129.458(H)×0.8(D) mm
Luminance	0 cd/m²
View Direction	Symmetry
Viewing Angle	80/80/80/80 (Typ.)(CR≥10)
Plate Thickness	0.20+0.20 mm
Support Color	16.7M 70% NTSC
Weight	-
Frame Rate	-
Treatment	Without Polarizer
Contrast Ratio	1000:1 (Typ.) (TM)
Response Time	25 (Typ.)(Tr+Td)
Operating Mode	IPS Pro, Normally Black, Transmissive
Transmittance	10.9% (Typ.)(without Polarizer)
Light Source	No B/L
Designed For	Mobile Phone
Touch Panel	Without
D-IC Detail	COG Suggest OTM1287A, OTM1289A, OTM1290A, HX8394-F, ILI9881C, NT35521S, NT35521Z, JD9365D
Environment	Operating Temperature: -20 ~ 70 °C; Storage Temperature: -30 ~ 80 °C

HSD055BHW7-P00 LCD Panel Note :

Model Verification:

Please ensure that the model number you need is exactly the same as the model number you have ordered. We will ship the LCD panel based strictly on the model specified in your order. Ensuring the correct model number is crucial to avoid any compatibility issues.

Comprehensive Testing:

We conduct 100% testing on each LCD panel to ensure it meets our stringent quality standards. This thorough testing process guarantees that you receive a fully functional and reliable product. Our commitment to quality ensures that each panel is meticulously checked before it is shipped to you.

HSD055BHW7-P00 LCD Panel Shipping and Package :

Original 5.5 inch HSD055BHW7-P00 LCD Screen Monitor 0

HSD055BHW7-P00 LCD Panel Shipping Guidelines:

Address Confirmation:

It is crucial to verify that the shipping address provided in your order is accurate. We will ship the LCD panel to the address listed in the order. If you need the panel to be shipped to a different address, please email us the new address immediately after making the payment to avoid any shipping errors.

Shipment Timeline:

Your order will be processed and shipped within three business days after we have received your payment. Please note that business days do not include weekends or public holidays, so take this into account when estimating your delivery date.

HSD055BHW7-P00 LCD Panel ESTIMATED DELIVERY TIME :

Standard Shipping:

The estimated delivery time for standard shipping is between 10 to 35 working days. This timeframe may vary depending on the destination and other factors such as customs processing and local postal services.

Expedited Shipping:

For a faster delivery option, expedited shipping is available with an estimated delivery time of 4 to 7 working days. This option is ideal if you need the LCD panel urgently and prefer a quicker shipping method.

HSD055BHW7-P00 LCD Panel FAQ :

Q: Can You declare my order of HSD055BHW7-P00 to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .

Q: How can I trace my order of HSD055BHW7-P00 ?

A: we will give you tracking number then you can trace your order from website.

Q: How long will I receive my goods HSD055BHW7-P00 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.

Q: How to make payment of HSD055BHW7-P00 ?

A: We accept T/T , Paypal , western union .
