5.0 inch HSD050B8W9-A00 480*960 LCD Screen for Mobile Phone

Brand Name:	HannStar
Model Number:	HSD050B8W9-A00
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

HSD050B8W9-A00

Diagonal Size:

Panel Type:

A-Si TFT-LCD, CELL, Q-CUT (Full Cell)

Resolution:

480(RGB)×960 217PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

56.16(W)×112.32(H) Mm

Designed For:

Mobile Phone

Driver IC:

COG Suggest ILI9806E, JD9161, OTM8019A

Display Colors:

16.7M 59%NTSC

Environment:

Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C

Supply Ability:

100000 Unit/Units per Month

Product Description

5.0 inch HSD050B8W9-A00 480*960 LCD Screen for Mobile Phone

HSD050B8W9-A00 LCD Panel Product details :

Brand	HannStar
Model P/N	HSD050B8W9-A00
Diagonal Size	5.0"
Panel Type	a-Si TFT-LCD, CELL, Q-CUT (Full Cell)
Resolution	480(RGB)×960 217PPI
Pixel Format	RGB Vertical Stripe
Active Area	56.16(W)×112.32(H) mm
Bezel Opening	-
Outline Size	58.56(W)×118.52(H)×0.8(D) mm
Surface	Without Polarizer
Brightness	0 cd/m²
Contrast Ratio	800:1 (Typ.) (TM)
Viewing Angle	70/70/70/60 (Typ.)(CR≥10)
Display Mode	TN, Normally White, Transmissive
Best View on	12 o'clock
Response Time	4/12 (Typ.)(Tr/Td)
Glass Depth	0.40+0.40 mm
Transmissivity	3.9% (Typ.)(with Polarizer)
Display Colors	16.7M 59%NTSC
Lamp Type	No B/L
Frequency	-
Touch Screen	Without
Driver IC	COG Suggest ILI9806E, JD9161, OTM8019A
Panel Weight	TBD
Application	Mobile Phone
Environment	Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C

HSD050B8W9-A00 LCD Panel Note :

Model Verification:

Please ensure that the model number you need is exactly the same as the model number you have ordered. We will ship the LCD panel based strictly on the model specified in your order. Ensuring the correct model number is crucial to avoid any compatibility issues.

Comprehensive Testing:

We conduct 100% testing on each LCD panel to ensure it meets our stringent quality standards. This thorough testing process guarantees that you receive a fully functional and reliable product. Our commitment to quality ensures that each panel is meticulously checked before it is shipped to you.

HSD050B8W9-A00 LCD Panel Shipping and Package :

5.0 inch HSD050B8W9-A00 480*960 LCD Screen for Mobile Phone 0

HSD050B8W9-A00 LCD Panel Shipping Guidelines:

Address Confirmation:

It is crucial to verify that the shipping address provided in your order is accurate. We will ship the LCD panel to the address listed in the order. If you need the panel to be shipped to a different address, please email us the new address immediately after making the payment to avoid any shipping errors.

Shipment Timeline:

Your order will be processed and shipped within three business days after we have received your payment. Please note that business days do not include weekends or public holidays, so take this into account when estimating your delivery date.

HSD050B8W9-A00 LCD Panel ESTIMATED DELIVERY TIME :

Standard Shipping:

The estimated delivery time for standard shipping is between 10 to 35 working days. This timeframe may vary depending on the destination and other factors such as customs processing and local postal services.

Expedited Shipping:

For a faster delivery option, expedited shipping is available with an estimated delivery time of 4 to 7 working days. This option is ideal if you need the LCD panel urgently and prefer a quicker shipping method.

HSD050B8W9-A00 LCD Panel FAQ :

Q: Can you tested the HSD050B8W9-A00 before shipping ?

A: Of course , our lcd panel HSD050B8W9-A00 was Strictly tested before shipping.

Q: How to order HSD050B8W9-A00 ?

A: We accept T/T , Paypal , western union .

Q: How long the warranty of the lcd HSD050B8W9-A00 ?

A: 90 days .

Q: What happen if the lcd panel HSD050B8W9-A00 I received can't work ?

A: HSD050B8W9-A00 was tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel .
