Name: Original 1920*1080 M215HGJ-P02 21.5 inch 60Hz LCD Screen
Brand: Shenzhen Yongsheng Innovation Technology Co., Ltd
SKU: M215HGJ-P02
Availability: InStock

Brand Name:	Innolux
Model Number:	M215HGJ-P02
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

M215HGJ-P02

Diagonal Size:

21.5"

Panel Type:

A-Si TFT-LCD, CELL, FOB

Resolution:

1920(RGB)×1080, FHD 102PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

476.64(W)×268.11(H) Mm

Used For:

Desktop Monitor

Transmissivity:

6.1% (Typ.)(with Polarizer)

Work Mode:

TN, Normally White, Transmissive

Response:

1.5/3.5 (Typ.)(Tr/Td) Ms

Supply Ability:

100000 Unit/Units per Month

Product Description

Original 1920*1080 M215HGJ-P02 21.5 inch 60Hz LCD Screen

M215HGJ-P02 LCD Panel Product details :

Brand	Innolux
Model P/N	M215HGJ-P02
Diagonal Size	21.5"
Panel Type	a-Si TFT-LCD, CELL, FOB
Resolution	1920(RGB)×1080, FHD 102PPI
Pixel Format	RGB Vertical Stripe
Active Area	476.64(W)×268.11(H) mm
Bezel Opening	-
Outline(mm)	487.14(W)×280.41(H)×1.43(D)
Luminance	0 (cd/m²)
Viewing Angle	85/85/80/80 (Typ.)(CR≥10)
Good View at	6 o'clock
Glass Thickness	0.50+0.50 mm
Color Depth	16.7M 72% NTSC
Mass	435/455g (Typ./Max.)
Refresh Rate	60Hz
Treatment	Antiglare (Haze 25%), Hard coating (3H)
Contrast Ratio	1000 : 1 (Typ.) (TM)
Work Mode	TN, Normally White, Transmissive
Response	1.5/3.5 (Typ.)(Tr/Td) ms
Transmissivity	6.1% (Typ.)(with Polarizer)
Backlight	No B/L, No Driver
Used for	Desktop Monitor
Touchscreen	Without
Driver IC list	Built-inCOG6 source COF + 3 gate COG chips
Signal Type	LVDS (2 ch, 8-bit), 30 pins Connector
Voltage Supply	5.0V (Typ.)
Max. Ratings	Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C

M215HGJ-P02 LCD Display Features :

High Quality:

Highest quality touch LCD screen replacement parts.

Repair Utility:

Suitable for repairing faulty screens, touch screen problems, dead pixels, cracked touchscreens, and other related issues.

Thorough Testing:

Each assembly is tested before shipping to ensure 100% functionality.

Quality control includes checks for dark spots, color points, and dead pixels, ensuring no defects.

M215HGJ-P02 LCD Panel Shipping and Package :

Original 1920*1080 M215HGJ-P02 21.5 inch 60Hz LCD Screen 0

M215HGJ-P02 LCD Display Shipping Policy :

Shipping Method:

If the buyer selects a specific courier (e.g., FedEx), we may ship the product using an equivalent service level from other logistics companies such as DHL, UPS, TNT, or others.

Specified Logistics:

If you require a specific logistics company, please inform us in advance.

M215HGJ-P02 LCD Display Return Policy :

Product Status:

The product's condition (new or old) will be indicated in the product title.

Return and Exchange Conditions:

If the product encounters quality problems within 30 days of receipt, we offer free returns and exchanges.

Return Procedure:

When returning the product, please provide a detailed explanation of the issues encountered.

Include actual photos showing the problems with the product.

M215HGJ-P02 LCD Panel FAQ :

Q: How long is the warranty of M215HGJ-P02 ?

A: 90days warranty .

Q: Can you give me a discount if I need a large quantity of M215HGJ-P02 ?

A: Of course!If you make a large order, we will give you a discount.

Q: How can I trace my order of M215HGJ-P02 ?

A: we will give you tracking number then you can trace your order from website.

Q: Can I pay my goods M215HGJ-P02 by credit card ?

A: Yes!you can use your credit card through your Paypal account.
